Stx2401 Full-Automatic Diamond Wire Saw
| Price: |
US $ 99-7999/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal |
Product Description
| Model: | STX-2401 Full-automatic Diamond Wire Saw |
Brief
Introduction: | STX-2401 Full-automatic Diamond Wire Saw is designed for cutting different hardness of crystal, ceramic, glass, rock, meteorites samples, ocean concretion, refractory,composite.Max.Cutting dimension is 24 inches. |
| Main Feature: | 1.Cutting different hardness of crystal, ceramic, glass, rock, refractory, especially for processing fragile and easy disintegrating crystal.
2.Diamond wire is driven by main motor;Can set speed up and down;The sample is fasten on the working platform, so can make it stably.
3.Can make all kinds of fixtures for different clients, suitable for different shape of objects.
4.Aluminum structure, beautiful and stable.
5.Imported pneumatic element, can make tension reliable and stable.
6.PLC program control, easy to operate.
7.Big touch screen, beautiful shape, good touching |
Technical
Parameter: | | Max.Z-axis platform travel distance | ≤700mm | | Min .Z-axis platform feed speed | 0.01mm/min | | Max.Z-axis platform feed speed | 60mm/min | | Max.Processing sample dimension | 600X600mm | | Dia.Wire | ≤0.45mm | | Wire total length | ≤270M | | Cutting wire speed | 0~4.3M/S | | Limit tension force | 0.4MPa | | Guide wheel centre torque | 924mm | | Voltage | AC220V | | Power | 300W | | Noise | ≤80dB | | Weight | 400kg | | Size | 1454mmX1404mmX2490mm |
|
| company information | Laizhou Weiyi experimental machine manufacturing Co.,Ltd. was established in 2001,covering 55 acres,which is one leading enterprise in the field of a professional R&D,manufacturing metallographic sample preparation erquipment. Was identified as Technology high-tech enterprises by Shandong Provincial Science , Shandong Academy of Sciences Research Building . |
| In 2004 the company passed the ISO9001 quality management system certification,in 2012 the company obtained CE certification, laid the foundation for a comprehensive international markets. |
Laizhou Weiyi Experimental Instrument Manufacturing Co. Ltd. Is engaged in domestic metallographic sample preparation equipment, sample preparation supplies R & D, production and sales of leading enterprises. The company was founded in 2001, covering an area of 55 acres. We have 110 staff at present, among which there are 32 engineering and technical staff, 17 staff working for products and technology development. We are a high-tech enterprises authorized by Shandong science and technology department, as well as the base on scientific research in Shandong province.
In 2004, the company passed the ISO9001 quality system certification.
In 2005 we achieved the independent right of import and export.
In 2011 we first achieved CE certification in the domestic industry, laying the foundation for the comprehensive development of international market.
We have established 3 sales companied in China, more than 200 dealers. Meanwhile we have more than 20 foreign agents in the world.
We have been focusing on the investment in technology development. In recent years we have developed a number of international advanced level of metallographic sample preparation equipment. We have won 4 national invention patents, dozens of patents of utility model patents as well as the appearance patents. Several products can replace the imported products, which makes the "WEIYI"brand the leading brand in the domestic industry.
Welcome all friends at home and abroad to our company for visits
