| Prod Model: |
CSL-STX815M |
| Model: |
Stx815m |
| Hf: |
1 X 1.7 Inch Diaphragm |
| Lf: |
1 X 15 Inch Woofer |
| Frequency Response: |
55Hz - 20 kHz |
| Rated Power: |
800W |
| Impedance: |
8ohms |
| Sensitivity: |
96 dB |
| Maximum Spl: |
131 dB |
| Products Packing: |
Packaged in Carton Case or Flight Case |
| Warranty: |
2 Year |
| Noise: |
<95dB |
| Hi-Fi: |
Not Hi-Fi |
| Speaker System: |
2.0 Channel |
| Speaker Material: |
Wood |
| Application: |
Home |
| Certification: |
FCC |
| THD: |
<0.005% |
| Operation Mode: |
Cable Connecting |
| Monitor: |
No LED |
Product Description
Stx815m 15" 2-Way Audio Sound System Monitor Speaker15" Two-Way, Bass-Reflex, Stage Monitor/Utility
A single 15" lightweight two-way system designed to function as a high-power handling, FOH loudspeaker system or as an extended range floor monitor, it offers an extremely high level of performance either ground, pole or stand mounted. A 70 degree by 70 degree coverage angle for focused directivity control.
Features:
--Compact and low-profile for minimal obstruction of audience sight-lines.
--70° X 70° Nominal coverage.
--Bi-amplified or full-range passive operation.
--Pole socket for applications requiring pole or tripod mounting.
--Twelve M10 suspension points.
--High power handling, low distortion Vented Gap Cooling™ LF driver.
--3 in. (diaphragm) neodymium magnet compression driver.
--Rugged DuraFlex Coated enclosures sized to be truck pack friendly.
--14-Gauge steel grille lined with acoustically transparent cloth.
| Stage Monitor Speaker (Stx815m ) |
| Specifications: |
| Frequency Range (-10dB): | 41 Hz-20 kHz |
| Frequency Response ( ±3dB): | 55 Hz-20 kHz |
| Coverage Pattern: | (70×70)degree nominal |
| Sensitivity (1W/1m): | 96 dB |
Power Rating:
(Cont.Pink Noise/Program/Peak) | 800W/ 1600W/ 3200W
(Continuous/Program/Peak) |
| Rated Maximum SPL: | 131 dB SPL Peak |
| Nominal Impedance: | 8Ω |
| Input Connectors: | Two NL4 |
| Operational Modes: | Full Range/Bi-Amp |
| Dimensions (H x W x D): | 721 mm x 436 mm x 329 mm
(28.4" x 17.2" x 13.0") |
| Net Weight: | 26 kg (58 lbs) |
