| Prod Model: |
MInC-2 |
| Hand Tool: |
Car Glass Reapir Tool |
| Name: |
Car Window Repair Tools. |
| Useful: |
for Car or Glass |
| Function: |
Car Windshield Repair Tools |
| Certification: |
According to Customer's Request |
| Type: |
Car Glass Repair Tool |
| Standard: |
Other |
| Tire Gauges Type: |
No |
| Tire Gauges Carry Way: |
No |
| Update Method: |
Other |
Product Description
SuperPDR drill free vacuum glass repair tool car window glass repair tools
Solution to Permeation FailureThe reason why the repair will fail always goes to the shattered remains and dust since it has been broken for a long time, thus stopping the repair liquid from permeation even under the vacuum state. It is strongly suggested to have a small hole perforated on the obstructed crack. Then repair again with another vacuum repair tool according to the operation instruction steps.Repair InstructionAttention: Please avoid any repair under a blazing sun. Fit to repair indoors or underground garage.- Keep the damaged parts dry and avoid surface cleaning with any liquid.
- Remove the debris of the damaged surface with knife tip
- Fold the label film in half and cut a hole as large as the crack.
- Remove the protective layer of the label film..
- Paste the film by aligning with the crack center. Then smooth the film to eliminate bubbles.
- Smear the glue evenly on the peripheral part of vacuum repair sucker to enable a vacuum state for the crack.
Don't apply glue on the crack's reach area in case of repair failure caused by obstructed crack. 7. Paste the vacuum repair sucker right on the crack's center point with precision.
8. Smooth the glue evenly to guarantee no air leak in the peripheral and out of crack's reach. The solidification time must over 30 minutes.
9. After solidification completed, insert into the value core's bottom with syringe to exhaust air gradually and slowly for about 2 to 3 times, until the repair liquid covering area has been vacuum.
10. The liquid use amount depends on the crack size. Stop adding when the crack has been filled up. Two bottles of liquid are highly recommended.11. Upturn the needle and eliminate the air in the syringe completely, making it filled with repair resin inside. No air should be left inside. 12. Insert into the value core's bottom with syringe. Slowly inject the resin until the repair area has been filled up.13. Stay in car to observe the permeating state of glass crack for 3 to 5 minutes. The cracks will be fading gradually during the permeation and finally disappear.14. Inject 5ml of air to the vacuum repair sucker after solidified for about 20 minutes. Make sure the resin has fully permeated into the crack with the help of self vacuum state and the external high pressure. 15. Extract the redundant repair liquid after the permeation done. Reduce the air pressure inside.16. Remove the label film and vacuum repair sucker.17. Instantly paste the cured film on the crack to achieve better results.18. Expose the crack under a blazing sun for 10 to 15 minutes or under the UV curing light for about 5 minutes.19. Remove the cured film and scrape the adhesive residue.20. Repair done.
