Prod Model: |
B87C, TCA-7, TPB40, TPB60, TPB90 |
Weight: |
32-56kg |
Processing Type: |
Forging |
Material: |
High Manganese Steel, Tungsten Carbide |
Use: |
Coal Mining, Quarry Drilling or Well Drilling |
Transfer: |
Air/Sea/Express |
Color: |
Request |
Power Type: |
Air Compressor |
Product Name: |
Rock Drill/Jack Hammer |
Working Pressure: |
0.63MPa |
Air Consumption: |
32-42(L/S) |
Certification: |
API |
Condition: |
New |
Type: |
B87c, TCA-7, Tpb40, Tpb60, Tpb90 |
Application: |
Splitting and Construction |
Product Description
Product Description:Paving breaker uses the compressed air as a driving force. It can efficiently complete strengthen of concrete and the breaking of rocks and asphalt. The compressed air is distributed alternatively through the distributing valve into either end of the cylinder assembly so that the hammer inside is made to carry on a reciprocaql motion which impacts the shank of the steel chisel by the tappet drives the chisel into the concrate foundation and makes them split into huge pieces.
And it is more high-powered, more efficient and has much longer life. Especially, for the crushing of Large, thick, hard objects, it is the ideal tool to the foundation constructions, such as the Mines, bridges, roads, municipal construction, etc.
Specification:|
TYPE | TPB90 | TPB60 | B87C | RB777 |
WEIGHT(KG) | 42 | 42 | 39 | 37 |
LENGTH(MM) | 723 | 723 | 686 | 733 |
CYLINDER DIA(MM) | 66.67 | 57.15 | 63.5 | 57 |
AIR COMSUMPTION(L/S) | 37 | 33.4 | 55 | 34 |
WORKING PRESSURE(Mpa) | 0.63 | 0.63 | 0.63 | 0.63 |
AIR PIPE INNER DIA(MM) | 19 | 19 | 19 | 19 |
PISTION STROKE(MM) | 152 | 100 | 100 | 189 |
SHANK SIZE-1 | 28*152MM | 28*152MM | 28*152MM | 32*152MM |
1 1/8 * 6 INCH | 1 1/8 * 6 INCH | 1 1/8 * 6 INCH | 1 1/4 * 6 INCH |
SHANK SIZE-2 | 32*152MM | 32*152MM | 32*160MM | |
1 1/4 * 6 INCH | 1 1/4 * 6 INCH | | |
FAQ:Q1: Can I have a sample for testing?
A:Samples are still to be paid but discounted price can be provided.
Q2: Do you have the inspection procedures?
A:100% strict inspection and testing for every order before packing.
Q3: How can i get the after sale services?
A:Free replacement will provide once the problems casued by our product quality.
Q4: Can I have a visit to your factory before the order?
A: Sure, welcome, here is our address: Yantai, Shandong.
CONTACT:
Pandadrill, founded on 2008 year, is a specialized manufacturers and supplier of Rock Drilling Tools, Stone and demolition tools and consumables for quarrying, mining and construction with 10 years experiences.
We produces high quality rock drilling products by using high quality raw material, utilizing advanced craft technology and imposing strict quality inspection. The products made by Pandadrill are being adopted by various users from all over China and exported to more than 50 countries including America, France, Australia, Canada, Brazil, South Africa, Malaysian, South Korea and other countries. All of our products are highly-reputed by our customers.
Pandadrill tools always committed to provide low cost Rock Drills, stone tools, rock drilling tools, high efficiency drilling tools, energy saving and environmental product for domestic and international clients.
"Continues to provide you with better products", which keep business purposes, we still make constant efforts to adhere to yesterday's achievements as a starting point, whole-heartedly to create first-class products and good services for all customers, in order to create the endless space and wealth for all customers. We believe in Fair Quality, Fair Price, Fair Trading, we are aim to provided quality, convenient, quick service to customer and have gained good reputation in the market.
We are confident for our products and technology and we are always improving our product quality and service to satisfy our clients' various requirement.
Main products:
SMALL HOLE DRILLING TOOLS
TOP HAMMER DRILLING TOOLS
HAND HELD DRILLING MACHINE
DTH TOOLS
ROTRAY DRILL TOOLS
BREAKING TOOLS (STONE & CONSTRUCTION)
GRINDING TOOLS
STONE CUTTING TOOLS
MINING EQUIPMENT
