Through Reverse Circulation DTH Hammers (GLF345)

Through Reverse Circulation DTH Hammers (GLF345)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: GLF345
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

RC DTH Hammer

Products Features:

1. a good effect in exhaust rock power, reduce re-breaks of rocks' power, and lessen the damage of drill to advance drilling efficiency.

2. high-ability in flush off and high drilling efficiency

3. compression gas and feeding back liquid should all be transferred in the enclosed pipe to avoid the crash on the hole side, largely reduce the breaking rate, keep the holes' stability and have an unique effect on the complicated ground.

4. rocks' sample will be transferred to the ground without touch on the side to avoid the pollution

5. the powder will be flushed to the designated place to muster treatment and have a exact judgment on the floors' change. Furthermore, it is good to pollution and benefits the working environment and high working life.

6. simple structure is convenient to maintain and to change the easily-damaged spare parts.


Products Scope:

Mainly in water wells, ground-hot air-condition well, exploring floor, complex floor and so on.

Item GLF345
Drilling Dia (Φ /mm) 110-130
Hammer Length (mm) 1281
Outside Dia (Φ /mm) 105
Center Hole Dia. (Φ /mm) 36
Working Pressure (Mpa) 0.7-2.1
Air Consumption (M3/Min) 5.7-14.2
Torque (N. M) 600
Impact Frequency (Times/Min) ≥ 800
Connection 1 API 2-7/8"
Glorytek Industry (Beijing)Co., Ltd., located in Beijing, China, is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for decades. We are supported and assisted by a highly experienced team of designers and engineers that enable us to complete all the assigned projects successfully as per the specified requirement from our clients.

Our products are widely used in the scope of mining, water well drilling and exploration, anchor grouting project, side slope protection engineering, oil and gas engineering, underwater rock drilling & blasting operations of seaport channel, hydropower project, national defense projects ect.

Due to the continuous effort and improvement, Glorytek's market share keeps increasing rapidly, meanwhile, the perfect after-sales service is providing a strong support and guarantee for the expanding of business cooperation. Till now, we enjoy the good reputation and our products have been winning the confidence of a lot of domestic and overseas customers.

Scope of products:

Blasthole Drilling Rigs
1: Compressor Integrated Type
2: Compressor Separated Type

Water Well Drilling Rigs
1: Truck Mounted Type
2: Crawler Type
3: Trailer Type

Piling Machinery
1: Rotary Drilling Rigs
2: Anchor Drilling Rigs
3: Auger Drilling Rigs

Drilling Auxiliaries
1: DTH Hammer and Bits
2: Button bit, Chisel bit, Cross Bits
3: Drill Pipe or drill Rod
4: Tricone Bits
5: PDC Bits
6: Downhole motor or Mud Motor
7: Pumps
