| Prod Model: |
CHD003 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Eastern Asia |
| Size:: |
4"-14" |
Product Description
Turbo wave Diamond saw bladeApplication: Dry or wet for the fast cutting of concrete, marble, granite, brick, block and ithere material.
Processing: Hot pressing
Size: 350mm
OUTER
DIAMETER | HOLE DIAMETER | SEGMENT DIMENSIONS | NUMBER OF SEGMENT | CORE THINCKNESS |
| INCH | METIRIC | THICKNESS | HEIGHT |
| 4" | 105 | 20 | 1.8 | 7.5 | 8 | 1.2 |
| 4" | 110 | 20 | 1.9 | 12 / 10 | 8 | 1.2 |
| 41/2" | 114 | 20 | 2.0 | 12 | 8 | 1.2 / 1.4 |
| 6" | 150 | 22.2 / 25.4 | 2.1 | 7.5 | 11 | 1.2 / 1.4 |
| 7" | 180 | 22.2 / 25.4 | 2.2 | 7.5 | 14 | 1.2 / 1.4 |
| 8" | 200 | 22.2 / 25.4 | 2.4 | 7.5 | 14 | 1.2 / 1.4 |
| 9" | 230 | 22.2 / 25.4 | 2.4 | 7.5 | 16 | 1.2 / 1.4 |
| 10" | 250 | 22.2 / 25.4 | 2.6 | 7.5 | 18 | 1.2 / 1.4 |
| 12" | 300 | 22.2 / 25.4 | 2.8 | 7.5 | 22 | 1.2 / 1.4 |
| 14" | 350 | 22.2 / 25.4 | 2.8 | 7.5 | 24 | 1.2 / 1.4 |
Zhejiang changheng tools co. Ltd is seated in hardware city -yongkang, it' S profession saw blade manufacturer. The product is involved with Tungsten carbide tipper circular saw blades, Diamond saw blade, mower saw blades etc, we can offer hundreds type of specification based on different saw blade. So far, the company covers an area over 30, 000 square meters and an annual production over 20, 000, 000 saw blades. The product will be exported many countries such as MID-east, Asia, Europe, America etc.
To ensure the good quality, the company adopts the most advanced technology and device from Japan and Germany. And make our work shop form one set completely speciialized production line. What' S more we also improve our management strategies on time and our company passed ISO2000 quality system Authentication in 2003, our product passed TUV certification.
The company will do its utmost to cultivate our famous brand and sincerely welcome merchants from home and abroad to cooperate with us!
