galvanized black 134 banded beaded service Tee Malleable cast iron pipe fittings
Size
1/2"-4"
Type
Banded, Beaded, Plain; with rib, or without rib.
Thread Standard
British standard American standards Din standard
Finish
Black, Eclectic Galvanized, Hot Dipped Galvanized, all be antirust treatment
Quality Control
Excellent material, precise angles, good antirust property
Material and Standard
Malleable iron, meet standard ASTM A197
Dimensions
ANSI/ASME B16.3-92/B1.21.1-83
Galv Standard
ASTM A153
Producing Technology
Pattern making -sand casting -heat treatment-surface treatment-machining-packing
Chemical and Physical Properties
Chemical Properties
Physical Properties
C %
Si %
Mn %
P%
S%
Tensile Strength
Elongation
2.4-2.9
1.4-1.9
0.4-0.65
<0.1
<0.2%
≥330 Mpa
≥8%
Hardness: <150HB
Hydraulic Pressure Test:
3-5Mpa, Working Pressure:1.6Mpa., 100% test before shipment
Packaging & Delivery
Packaging Details
Boxes, Cartons, Pallets, Single plastic Bag
Delivery Time
Shipped in 45 days after payment
We supply high quality gavanized and black malleale iron fittings, UL FM Ductile iron fittings and Cast iron fittings. Please contact if you have any questions.
We supply different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will reply you as soon as possible. We stick to the principle of " Quality first, service first, continuous improvement and innovation to meet the customers" For the management and " Zero defect, zero complaints" As the quality objective.
