Prod Model: |
yt24, yt27, yt28, yt29a, yt18, yt26 |
Drilling Diameter: |
32-65mm |
Processing Type: |
Forging |
Material: |
High Manganese Steel, Tungsten Carbide |
Use: |
Coal Mining, Quarry Drilling or Well Drilling |
Transfer: |
Air/Sea/Express |
Color: |
Request |
Power Type: |
Air Compressor |
Product Name: |
Rock Drill/Jack Hammer |
Working Pressure: |
0.4-0.8MPa |
Air Consumption: |
85(L/S) |
Working Style: |
Rotary Type |
Brand: |
Panda |
Type: |
Drill Tools |
Product Description
Product Description:Air leg rock drill is rock drilling equipment with high high impact energy, and lower air comsumption,
it is widely fitting for coal mine, railway traffic, water conservancy and so on.
Panda Pneumatic Rock Drill have water flushing, gun bar rotation and the pusher leg control is placed at the back head of the rock drill. An in-line lubricator is included in the delivery of each rock drill. together with the appropriate pusher leg.
Advantage:
1). save energy and high efficiency
2). strong impact energy
3). low vibration
4). easy handling
5). low noise
6). wet drilling
7). easy cleaning air /water holes
8). spare parts easily purchasing
Specification:TYPE | YT24 | YT27 | YT28 |
WEIGHT(KG) | 24 | 26 | 26 |
SHANK SIZE(MM) | 22*108 | 22*108 | 22*108 |
CYLINDER DIA(MM) | 70 | 80 | 80 |
PISTON STROKE(MM) | 70 | 60 | 60 |
WORKING PRESSURE(Mpa) | 0.4~0.5 | 0.4~0.5 | 0.4~0.5 |
IMPACT FREQUENCY(Hz) | 34 | 36 | 36 |
AIR CONSUMPTION (L/S) | 55 | 85 | 75 |
AIR PIPE INNER DIA(MM) | 19 | 25 | 25 |
ROCK DRILL HOLE DIA(MM) | 30~45 | 30~45 | 30~45 |
ROCK DRILL HOLE DEPTH(M) | 6 | 6 | 6 |
FAQ:Q1: Can I have a sample for testing?
A:Samples are still to be paid but discounted price can be provided.
Q2: Do you have the inspection procedures?
A:100% strict inspection and testing for every order before packing.
Q3: How can i get the after sale services?
A:Free replacement will provide once the problems casued by our product quality.
Q4: Can I have a visit to your factory before the order?
A: Sure, welcome, here is our address: Yantai, Shandong.
