| Prod Model: |
HX PCD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
PDC for Oil Drilling Industry |
| Certification: |
ISO9001 |
| Grade: |
a |
| Size: |
From 75mm to 450mm |
Product Description
Introduction
PDC bits uses PDC as main cutting components, with the excellent wear-ability and impact toughness of the PDC.
It has a long useful life, high-efficiency, and good cost performance.
PDC bit is mainly used for drilling soft and big drainage.
Specifications
1)Size from 75mm to 450mm
2)Super quality and competitive price
3)Meet the needs of the new and old customers
All of our business is carried out in full compliance with the ISO9001 Certification.
Please contact us if you would like any further information.
| Product Number | Diameter
(D)(mm) | Height
(T) (mm) | Diamond Thickness
(t) (mm) | Diamond
Chamfer
(mm) |
| 1308 | 13.44±0.03 | 8.00±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1313 | 13.44±0.03 | 13.20±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1608 | 15.88/16.00±0.03 | 8.00±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1613 | 15.88/16.00±0.03 | 13.20±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1908 | 19.05±0.05 | 8.00±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1913 | 19.05±0.05 | 13.20±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1916 | 19.05±0.05 | 16.31±0.10 | 2.30±0.20 | 0.30±0.10 |
