1600t Dme Die Cast Mold for Street Light Aluminum Part 72: )
| Price: |
NegotiableSet |
| Min Order: |
1Set |
| Pay Type: |
T/T |
| Prod Model: |
B2072 |
| Mold Insert Steel: |
Dievar/Orvar Supreme/1.2344/1.2343/Chinese H13 |
| Sample Material: |
ADC12/A360/A380/A413/ADC10 |
| Ability: |
Mold Fitting Machine up to 3200t |
| Material: |
Steel |
| Application: |
Street Lamp Shade |
| Surface Treatment: |
Nitride |
| Using Hardness: |
HRC46 +/-1 |
| Mould Life: |
120K Shots |
| Condition: |
New and Repeated |
Product Description
Brief Introduction of PrecisionerBasic Information
Company Name: Shenzhen Precisioner Diecasting Mold Co., Ltd.
Location: Shenzhen City, Guangdong Province, China
Founded in: 2009
Total Area: 43,000 square feet
Total Employment: around 110
Project Engineers: 17
Design Engineers: 12
Manufacture Engineers: 50
Mold Trial Engineers: 3
Quality Control Engineers: 8
Overseas Sales: 15
Business Range-Design and Manufacture:
a) High pressure die casting die (for Aluminum & Zinc parts, Vacuum System optional);
b) Trim tool;
c) Rapid prototype die casting die;
d) DME quick-change replacement unit die;
e) Separate components of all the above kinds of tools, such as mold base (retainer/holder block), replacement mold insert (cavity block), sub-insert, core pin, ejector pin, shot sleeve, sprue bush, sprue spreader, etc.;
f) Small lot production (pilot run) up to 1,000 shots with simplest post treatments, such as removing runners, overflow wells, flashes and burrs, for urgent projects.
For regular customers, we can also provide some engineering services, such as making DFM reports to help analyze a part, running a casting simulation, designing any kinds of tools described above, CNC machining parts for evaluation, etc.
Involved Industries
Automobile, Motorcycle, Aviation, Telecommunication, Medical Devices, Electrical Instrumentation, Machinery Equipment, Daily Hardware, Furniture Accessories, etc.
Market Distribution
Now we have regular customers from countries all over the world, such as the USA, Canada, Mexico, the UK, Germany, Italy, Denmark, Croatia, Poland, Australia and New Zealand, etc.
Qualification
Our factory has passed ISO 9001:2008.
ISO 14000 and TS16949 are also on our agenda.
Minimum Tolerance
≤0.02mm
Tooling Standard
DME, HASCO, NADCA
Software
a) ZW-CAD, and Auto CAD for 2D drawing;
b) UG for tooling design, and we can also accept and process the files from SolidWorks, ProE and CATIA;
c) Flow-3D for mold flow simulation, and now we are also studying EKK and Magma and hopefully will adopt in the future.
Tooling Material
ASSAB 8407 (Orvar Supreme) and ASSAB 8418 (Dievar) made by Uddeholm and imported by ASSAB Asia are the most frequently used materials for die cast mold insert, and ASSAB XW-42 from the same supplier is the most frequently used material for trim tool cutter. Original material certificates of purchase and heat treatment will be shipped together with the tooling we deliver to the customers.
T1 trial Success Rate
Over 95% of our built molds have been successful during T1 trial and then were directly put into mass production on our customer side, so sometimes some customers told us to immediately ship the tooling to them soon after manufacturing completed for some urgent projects.
Tooling Size
The smallest mold we've built was fit on 60T die cast machine;
The largest mold we've built was fit on 2,500T die casting machine;
The largest die cast machine we can access for mold trial is 3,200T;
The largest die weight we can handle is ≤ 15T;
The largest dimensions of mold we are able to build are as shown below:
a) Mold Insert: 900mm*1,600mm (designed and manufactured by Precisioner)
b) Mold Base: 2,000mm*1,500mm*1,500mm (cooperating with our mold base supplier)
Production Volume
Monthly: around 45 sets of mold (one set means one die casting die and one trim die)
Yearly: around 500 sets of mold (one set means one die casting die and one trim die)
Short Lead Time (from approval of the tooling design to T1 mold trial)
A) Estimated by mold size of longest side:
3-4 weeks: <500mm
4-7 weeks: 500-800mm
7-9 weeks: 800-1,200mm
9-12 weeks: 1,200-1,500mm
B) Estimated by die casting machine tonnage that runs the mold (by approximate statistics, in calendar days):
32 days: tonnage<500T
38 days: 500T42 days: 800T48 days: 1,600T
Competitive Price
Due to our grand development goals, we have adopted transparent and low rate of Return On Investment (ROI) policy as shown below:
1. For Die Cast Dies that fit DC machines > 800T, the ROI is only 12%!
2. For Die Cast Dies that fit 500T ≤ DC machines ≤ 800T, the ROI is only 17%;
3. For Die Cast Dies that fit DC machines < 500T, and all other kinds of tooling, the ROI is only 20%;
Transparent Price Structure
A simplified Quotation Sheet will be provided together with a Breakdown List that shows the price structure of tooling in detail, such as Design, Material Manufacture, Management, Profit Rate and Tax, etc.
Professional Services
a) Responding emails within 24 hours;
b) Offering quotation within 2 working days after the whole RFQ details received;
c) Providing DFM report and mold flow analysis report within 3 working days;
d) Providing initial tooling design within 3 working days;
e) Updating manufacturing progress plan every week after tooling design approval;
f) Sending in mold trial videos and sample photos within 2 working days after mold trial;
g) Shipping the mold trial samples within 2 working days after mold trial;
h) Sending in the sample inspection report in 3 working days after mold trial;
i) Shipping the tooling using your appointed freight forwarder or using our frequently-used forwarder within 4 working days after your approval;
j) Supplying all the following files together with the tooling: Mold Operation Instructions, Mold Trial Report and Recommended Casting Parameters, Steel Purchase Certificate and Heat-Treatment QC Report, Complete Mold Drawings, Mold Maintenance Recommendation, and so on.
Project Control-Five Meeting System
a) Project scheme review meeting-DFM confirmed;
b) Design review meeting-Initial Tooling Design confirmed;
c) Manufacture review meeting-Work Progress Plan confirmed;
d) Mold trial review meeting-Mold Trial Parameters & Process confirmed;
e) Summarization meeting after tooling delivery-Work Improvement Points confirmed.
Equipment List
6 CNCs: JTGK, GDM, MAKINO, HAWEST STAR
5 EDMs: JIAHENG, ESLY, HSPK
6 WEDMs: DAYU, XINKUAI
1 CMM: AEH
1 Fitting Machine(trim press): Nice 70T
2 Die Cast Machines for Die Trial only: LK IMPRESS-III 500T and 800T
1 Double-System Mold Temperature Controller (Die Heater): Aode
215 Fixtures: EROWA
1 Radial Drilling Machine: YILI
4 Milling Machines: DIC-W
2 Grinding machines: KENT
1 Lathe: NANHAI
4 Cranes: 5T, 7.5T, 5T+10T, DAXINGFA, YONGTONG
and many other ancillary facilities...
Precisioner's Vision, Mission and Values
Vision: To be the leading enterprise worldwide on designing and manufacturing die casting molds.
Mission: Focusing on customers' demands and challenges, supplying reliable die casting molds and holistic solutions, and persistently promoting customers' competition.
Values: Honesty, Responsibility, Concentration, Proactivity.
Precisioner Diecasting Mold Co., Ltd is a reliable diecasting mold manufacturer who focuses on integrated solution of zinc and aluminum diecasting mold, while provides one-stop service for customer, from optimize initial design, analyze budget scheme, CNC prototyping of conceptual product, design and manufacture of rapid prototype mold, mass production mold and its matching trim die, also provides small lot production, mold maintenance, repair, rebuild and refurbish service and so on. Our focus is mold itself, not providing large lot production of parts.
Precisioner Diecasting Mold Co., Ltd. is located in Guanlan Street, Longhua New district of Shenzhen. It was first established in Jincanda Industrial Park in Guanlan before moving to the Silicon Valley Power New Material Industrial Park in July of 2013, equipped with corollary equipments of manufacturing and inspecting diecasting mold, with over 70 engineers and technicians specialized in diecasting mold for years, Precisioner started exporting diecasting molds since 2009 and have already exported more than 2400 sets of diecasting molds and service. Our customers are mainly in America, Canada, Australia, Germany, Sweden, Portugal, Russia, Brazil, New Zealand, Chinese Guangdong Province, Shanghai city and so on. Precisioner supplies a wide range of industrial and commercial clients from automotive, communication, electric power, mechanical equipment, medical instrument, LED, household appliances, furniture and other leading industries. To better serve international clients, an office in Hong Kong Precisioner Industry ( HK ) Co., Ltd has also been set up.
Excellent Quality - On Time Delivery - Transparent Mold Cost
A reasonably optimal design scheme is the key of producing a high quality diecasting mold, we think highly of prophase design and spend much effort in analysis, discussion and modification to make the design scheme can avoid or prevent potential problem that will happen during mass production, on this basis, with precise machining process control, more than 90% of our produced diecasting mold can be directly into mass production after T1 and perform excellently, which help our customers save much time and cost, further gain larger competitive edge.
Delivery time is another vital factor of a successful project, and therefore we already have an elaborate progress plan and sound project leader system before a project starts, in the mean time, we will provide customers with weekly progress report and pictures in the manufacturing process, also welcome schedule inquiry and site inspection, consequently the problem of delayed delivery rarely happens.
On account of price disorder and asymmetric information of cost in mold manufacturing industry, what we provided for each RFQ is not only a total price, but also a break out list which contains each price component, including mold dimension, mold steel, tooling life, material cost, machining cost, administration cost, profit rate and so on, to let you know more.
Please take this opportunity to view our diecasting mold services in detail.
Not only a diecasting mold manufacturer, Precisioner Diecasting Mold Co., Ltd is also a provider of information and service, welcome to contact us for further inquiry.
