300m 500m Powerful Hydrogeological Core Drilling Machine Rig Xy-2b

300m 500m Powerful Hydrogeological Core Drilling Machine Rig Xy-2b
Price: US $ 20/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Drilling Method: Diamond Bit PDC Bit Air DTH Hammer Bit Drilling
Structure: Deep Hole Drilling
Layout: Vertical
Automatic Grade: Automatic

Product Description

2. Technical Specification:

hole diameter (mm):150
drilling angle:0 ~ 90
theoretical depth:30m~100m
power head push stroke:2500mm + chuck rear suspension of 1000mm
power head output speed (r/min): 0 ~ 350r/min
power head output maximum torque (N.m):4500N.m
power head stroke (mm): 1800
the power chuck hole:80mm
power head maximum feed force / pull force (kN):43/50 (0~44 continuously adjustable)
The rated pressure of hydraulic  (Mpa):18
diesel models:4100 diesel engine
hoisting capacity:3000Kg
host size (L*W*H) (mm):4200 x 2000 x 2000


3. Application and Feature:

(1) has the advantages of compact structure, convenient move and position;adopts full hydraulic control, flexible operation,time saving. Suitable for positive, Reverse Circulation DTH hammer construction.

(2) with low speed and high torque motor,so that the machine stable performance, reliable, long life.

(3) suitable for a wide range,drilling ability; power head is a through hole structure,high drilling efficiency.

(4) angle range, 0° to 90° .

(5) suitable for various drilling methods, mainly for the positive,Reverse Circulation DTH hammer.






Chongqing Gold Mechanical & Electrical Equipment Co., Ltd is a high-tech enterprise for researching, designing, developing and producing scientific and measuring instruments. With its continuous drawing of lessonas, unremitting innovation and borrowing of advanced technology from both at home and abroad, our company is now becoming a professional manufacture of oil tester, electric tester, laboratory instrument, road building instrument and geophysical equipment.

Though highly acclaimed and favorably accepted by numerous customers and possessed of the right to import and export, to ensure the high quality of our products, we conduct our manufacturing in strict accordance with various standards of ISO, ASTM D, IP, GB etc. We have developed sales channels in many countries and regions such as Thailand, Philippine, Iran, Indonesia, Spain, Iceland, Chile, Regions of Southeast Asia, Middle East, Europe, North and South America etc, and have gained strong advantage and high reputation in international market.

We have persisted on the business idea of "Integrity Basis and Quality First" for the stable and constant development. We are making effort to develop together with customers from both domestic and abroad on the basis of reciprocity. Client, quality and service are our supreme target!
