| Prod Model: |
LG400 Plasma Cutting Machine |
| CNC Interface: |
Yes |
| Color: |
Blue |
| Max Cutting Thickness: |
80mm |
| Attachment: |
2 Set of Water Cooler |
| LG400 Plasma Cutter Gross Weight: |
170kgs |
| LG400 Plasma Cutter Package Size: |
1380*882*610mm |
| Attachment Water Cooler Gross Weight: |
28kg/Set |
| Attachment Water Cooler Dimension: |
580*440*600 |
| Cooling Way: |
Water Cooling |
| Factory: |
100% Yes |
| Process Usage: |
Metal-Cutting CNC Machine Tools |
| Movement Method: |
Linear Control |
| Numerical Control: |
CNC/MNC |
| Control Method: |
Automatic / Manual |
| Processing Precision: |
±0.5mm |
| Performance Classification: |
Plasma Cutting Machine |
| Certification: |
CCC |
Product Description
Machine: Attachment: 1 set of water cooler
Plasma Gun (for option)
LG Plasma Cutting Machine Series
1. The product adopt advanced IGBT soft switch invert technology,greatly expanding the power source function ,improve the cutting speed,the cutting thickness up to 80 mm.Energy saving.
2. Combine new technology with carefully optimized craft, greatly reducing material consumption on main transformer, reactor and other material etc. Only one third weight, half volume compared with traditional air plasma cutting machine, the power factor is significantly improved. 3. Able to match with robots & CNC lathe,etc. Have arc voltage and arc-starting successful signal interface for robot control and CNC machine use.4. Simple and easy to use, stable performance. Concise operation panel, can preset cutting current precisely and conveniently by the numerical display of ammeter.
5. External HF arc-starting controller, little HF time, minimal environment interference. | ITEM | LG-60 | LG-100 | LG-130 | LG-200 | LG-400 |
| Input Voltages | 380V 50/60 Hz |
| Rated Input Capacity(KVA) | 9.7kw | 14.5 | 21.5 | 38 | 100 |
| Output Current(A) | 30-60 | 30-100 | 30-130 | 30-200 | 30-400 |
| Duty Cycle | 60% | 60% | 60% | 100% | 60% |
| Max. Cutting Thickness(mm) | 20 | 30 | 35 | 60 | 80 |
| Optimal Cutting Thickness(mm) | 0.3-10 | 0.3-22 | 0.3-25 | 1-45 | 1-55 |
| Gas Pressure(Mpa) | 0.3-0.5 | 0.4-0.6 | 0.45-0.6 |
| Cutting Torch Cooling Mode | Air Cooling | Air Cooling,Water Cooling |
| Dimension(H*W*L,mm) | 510*280*610 | 600*325*740 | 710*380*790 | 800*360*880 | 1260*540*830 |
| Weight(kg) | 35 | 53 | 75 | 82 | 170 |
Package:
FAQ:
1. Q: Certificate
A: ISO, CE, SGS, CCC
2. Q: Cutting Thickness Range ?
A: 0.3-80 MM
3. Q:Optimal Cutting Thickness Range?
A: 0.3-55 MM
4. Q:Cutting material?
A: All kind of sheet metal
5. Q:Lead Time, Delivery Time
A: 7 working days
6. Q:Warranty
A: 1 Year
7. Q: After service
A: 24 Hours Online Service, Free spare parts for breakdown machine in warranty service
8. Q:Portable or not?
A: Yes
Or you can tell me the following info, we'll suggest you the very item you need.
1. Material you'll cut.
2. Thickness of Material.
3. Cutting range (Length, width) you required.
4. Handheld torch or automated machine you required?
CHD WELDING
CHD was founded in 1989, is a High-Tech Enterprise which integrates R&D, Production, Sales and Service of cutting machine.
CHD, as one of the largest metal cutting machine manufacturers, headquartered in Shanghai, China. With 3 production bases, totally plant area of more than 53,000 square meters , respectively located in Shanghai, Chengdu and Wenzhou.
CHD focus on quality control, has passed many certification audits including ISO9000, SGS, CE, CCC, etc., was one of the world's largest manufacturer's partners of steel plate cutting equipment. CHD cutting machines have already been exported to more than 100 countries in the past 20 years.
Advantages of CHD
1. Large Production Capacity.
2. Full line of Products. Cutting Machine, Plasma Power, Welding Machine, Beveling Machine, Circular Cooling Water Tanks, Consumables.
3. Honesty. All parameters (cutting thickness & precision) are actual operation parameters without overstate.
4. Good after service, not one-off business.
5. One year guarantee. Free spare parts service on base of order amount. Engineer oversea service.
6. Adjustable Short Lead Time.
CHD was founded in 1989, is a High-Tech Enterprise which integrates R&D, Production, Sales and Service of cutting machine.
CHD, as one of the largest metal cutting machine manufacturers, headquartered in Shanghai, China. With 3 production bases, totally plant area of more than 53, 000 square meters, respectively located in Shanghai, Chengdu and Wenzhou.
CHD focus on quality control, has passed many certification audits including ISO9000, SGS, CE, CCC, etc., was one of the world's largest manufacturer's partners of steel plate cutting equipment. CHD cutting machines have already been exported to more than 100 countries in the past 20 years.
