| Prod Model: |
3.2.4.2.3 |
| Size: |
14 Inch |
| Manufacturing Arts: |
Welding |
| Saw Blade External Diameter: |
650mm |
| Kind: |
Diamond Laser Saw Blade |
| Usage: |
Concrete Cutting |
Product Description
650mm Circular Diamond Green Concrete Saw Blade with Long Lifetime
1. Description of 650mm Circular Diamond Green Concrete Saw Blade with Long Lifetime
As one of Diamond Cutting Blade Specialist and Diamond Tools Experts. You could find any diamond tool and diamond cutting blade that you want here.
650mm Green concrete diamond blade is premier product which combines high performance at a competitive price. It is designed to be used on both hand held and low horsepower walk behind saws. They are engineered with under cut protection segments to protect the core and extend blade life. Intended for use in hard aggregate.
Providing different bond specifications according to the type of concrete aggregates, reinforcing shares, and curing times.
2. Feature of 650mm Circular Diamond Green Concrete Saw Blade with Long Lifetime
1) Specially for cutting green concrete, new concrete, fresh concrete and other abrasive materials.
2) Different slot desigh as different cutting materials.
3) Protection segment against under cutting.
4) High speed&fast cutting.
5) Laser welding techology.
6) Cutting surface more smoothly, longer lifetime.
3. Specification of 650mm Circular Diamond Green Concrete Saw Blade with Long Lifetime
Diameter:650mm
Segment thickness:4.4mm
Segment height:10/12/15mm
Inner hole:25.4mm, 50mm, 60mm, 80mm or as your request
| Inch | Diameter
(mm) | Segment length
(mm) | Segment thickness
(mm) | Segment height
(mm) | Segment number
(nos) |
| 26" | 650 | 40 | 4.4 | 10 | 44 |
| 26" | 650 | 40 | 4.4 | 12 | 44 |
| 26" | 650 | 40 | 4.4 | 15 | 44 |
Other size Concrete Saw Blade we could do as following
| Inch | Diameter
(mm) | Teeth length
(mm) | Teeth thickness
(mm) | Teeth height
(mm) | Teeth number
(nos) |
| 6" | 150 | 34 | 2.2 | 7/10/12 | 11 |
| 8" | 200 | 40 | 2.4 | 7/10/12 | 13 |
| 9" | 230 | 37 | 2.6 | 7/10/12 | 16 |
| 10" | 250 | 40 | 2.6 | 10/12/15 | 16 |
| 12" | 300 | 40 | 3.0 | 10/12/15 | 18/20 |
| 14" | 350 | 40 | 3.2 | 10/12/15 | 21/24 |
| 16" | 400 | 40 | 3.4 | 10/12/15 | 24/28 |
| 18" | 450 | 40 | 3.6 | 10/12/15 | 28/32 |
| 30" | 750 | 40 | 5.0 | 10/12/15 | 50 |
| 32" | 800 | 40 | 5.0 | 10/12/15 | 46 |
| 36" | 900 | 40 | 5.0 | 10/12/15 | 64 |
4. Packing and Shipping
5pcs 650mm laser welded floor saw blades are packed in one plywood, gross weight per plywood is limited within 48kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
5. Payment term
T/T, Irrevocable L/C at sight,PayPal, West Union, Credit Card, etc.
6. Our Technology:
We are processing advanced production equipment, modern checking system, strict management and a strong technical force with the combination of many skilled workers and technical engineers.
Providing our customers with satisfactory diamond cutting tools is our aim!
