| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 5/Piece |
| Pay Type: | L/C,T/T,Paypal,Money Gram,Western Union |
| Prod Model: | HZDSW521 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Segment Material: | Diamond |
| Segment Type & Shape: | Normal, Turbo; Sandwich, Groove, etc |
| Base & Matrix Type: | Normal, Silent |
| Slot Type: | V Shape, U Shape(Narrow or Wide), Key Hole Shape |
| Manufacturing Art: | Welding |
| Usage & Application: | Cutting Granite, Marble, Sandstone, Concrete, Cemen |
| Cutting Direction: | Vertical Cut, Horizontal Cut |
| Cutting Condition: | Dry Cut, Wet Cut |
| Perfromance Comparison: | Sharp Diamond Blade, Wearable Diamond Blade |
| Quality Grade: | High, Medium, Normal |
| Graininess: | 100# |
| Thickness: | 5mm |
| Shape: | Round |
| Customized: | Customized |
| Usage: | Stone Cutting, Engineering Material, Fire-Retardant, Porcelain |
| Manufacturing Arts: | Welding |
| Kind: | Stone Sawing Machine |
| Specification: | 16 Inch |
| Brand: | Huazuan |
| Saw Blade External Diameter: | 800mm |
Descriptions of goods and Cutting performance | Applications | Suitable for granite ,mable,limestone ,sandstone, basalt , quartz etc stone cutting |
Welding | High-frequency weld , Laser weld , Brazed | |
Slot | Narrow slot/Key slot/U slot | |
Normal or Silent | Silent blade or Normal blade as you request | |
Blade Diameter (General purpose) | 10" - 140" as requested | |
Segment Qty | 17- 180 segments as requested | |
Segment Height | Dry H10/12mm , Wet H12-20mm | |
Inner Hole | 30mm/50mm/60mm | |
Type | Continuous rim & Segmented saw blade | |
More Sharpness | Diamond saw blade could survive from any destructive testing, the linear cutting speed reaches 7+ meter/min easily. | |
Longer Life-Span | Diamond saw blade have 50%+ longer life-span than common blades. For example: Asphalt cutting blade life-span reaches 88.5 square meter. | |
High CPR | We are keep trying to provide the best possible service for our customers, and offering the best world top quality products with as low as possible price. | |
Effectively | Diamond saw blade reduces the usage of electricity and the noise level during the op |
Out Diameter | Bore Diameter(mm) | Dimension of teeth(mm) | NO. of Teeth | ||
| Inch | mm | Thickness | Height | ||
| 10'' | 250 | 50/60 | 2.6/2.8 | 8/10/12 | 17 |
| 12'' | 300 | 50/60 | 2.8/3.0 | 8/10/12 | 21 |
| 14'' | 350 | 50/60 | 3.0/3.2 | 8/10/12 | 24 |
| 16'' | 400 | 50/60 | 3.4/3.6 | 8/10/12 | 28 |
| 18'' | 450 | 50/60 | 3.8/4.2 | 8/10/12 | 32 |
| 20'' | 500 | 50/60 | 4.0/4.2 | 8/10/12 | 36 |
| 22'' | 550 | 50/60 | 4.6/4.8 | 8/10/12 | 40 |
| 24'' | 600 | 50/60 | 4.6/4.8 | 8/10/12 | 42 |
| 26'' | 650 | 50/60 | 5.0/5.2 | 8/10/12 | 46 |
| 28'' | 700 | 50/60 | 5.0/5.2 | 8/10/12 | 50 |
| 30'' | 750 | 50/60 | 5.2/5.6 | 8/10/12 | 54 |
| 32'' | 800 | 50/60/80 | 5.5/6.0 | 8/10/12 | 57 |
| 36'' | 900 | 50/60/80/100 | 6.0/6.8 | 12/13/15 | 64 |
| 40'' | 1000 | 50/60/80/100 | 6.0/7.0 | 12/13/15 | 70 |
| 48'' | 1200 | 50/60/80/100 | 6.5/7.5 | 12/13/15 | 80 |
| 52'' | 1300 | 50/60/80/100 | 7.0/7.6 | 12/13/15 | 88 |
| 56'' | 1400 | 50/60/80/100 | 8.2/8.8 | 12/13/15 | 92 |
| 64'' | 1600 | 50/60/80/100 | 8.4/9.0 | 12/13/15/20 | 108 |
| 72'' | 1800 | 50/60/80/100 | 9.1/9.7 | 12/13/15/20 | 120 |
| 80'' | 2000 | 50/60/80/100 | 10.5/11 | 12/13/15/20 | 128 |
| 88'' | 2200 | 50/60/80/100 | 10.5/11 | 12/13/15/20 | 132 |
| 100'' | 2500 | 50/60/80/100 | 11/12 | 12/13/15/20 | 140 |
| 120'' | 3000 | 50/60/80/100 | 11.5/12.5 | 12/13/15/20 | 160 |
| 140'' | 3500 | 50/60/80/100 | 12/12.5 | 12/13/15/20 | 180 |
| Other specifications are available upon request. | |||||
Company Introduction:
Quanzhou Huazuan Diamond Tools Co.,Ltd.,established in 1994 and covering an area of more than 10,000 square meters,is an enterprise with more than 20 years' experience in research, development and production.
"HUAZUAN" means made in China,as solid and stable as diamond.Driven by diamond saw blade,diamond segment and diamond wire saw as for main products,company produce a series of high quality diamond grinding and polishing tools.
Continuous innovation are made with the aims to provide high efficient safe and environmental diamond tools for customers.
With the support of Huaqiao University Tool Research Institute as well as more than 20 years research and practice, we keep the lead of industry for product quality and producing technology,and build the outstanding business relationship with more than 50 countries and region partners.
We pursue the dreams that make HUAZUAN become the arena of realizing the dreams for clients,suppliers and staffs.In recent years,company make and practice a strategic plan to reinforce a high quality production system,create a consultant service team" and reached great success.
At present,China diamond tool constantly embody the competitiveness in the world ,we expect to contribute ourselves to change the poor quality image of China diamond tool in the world with our effect.
