Alloy Wheel Repair Diamond Cutting Vertical CNC Lathe

Alloy Wheel Repair Diamond Cutting Vertical CNC Lathe
Price: US $ 18500-19600set
Min Order: 1set
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: WRC28V
Max.Repair Wheel: 10-32inch
CNC Controller: Syntec
Machine Function: Diamond Cutting Wheel Rims
Motor Power: 11kw
Chuck Size: 400mm
Max.Swing Over Bed: 820mm
Spindle Speed: 50-1500rpm
Arbor Section: 20X20mm
Cutting Speed: 0.1-1000mm/Min
Tool Post Vertical Moving Distance: 200mm
Process Usage: Metal-Forming CNC Machine Tools
Movement Method: Point to Point Control
Control Method: Open-Loop Control
Numerical Control: CNC/MNC
Performance Classification: High-End CNC Machine Tools

Product Description

             alloy wheel repair diamond cutting Vertical CNC lathe




Product Description

Specification
ModelWRC30V
Max.Swing over bed800mm
Max.Diameter  of alloy wheel720mm
Chuck dia400mm
Spindle speed50-1500rpm
Cutting speed0.1-1000mm/min
Stations of tool carrier4 position tool post
Max.Size of tool post25×25mm
Main motor power5.5kW
Accuracy0.015 mm
Repeatability0.012mm
Net Weight≈3200kg
Machine size2250×1960×2300mm

Standard Components

1.Diamond Cutter
2.3-Jaws Manual Chuck(With Special Soft Jaws)
3.Diamond Digital Probe Tip
4.Taiwan SYNTEC Controller
5.Manual Quick Change Toolpost,Four-station;
6.Work Lighting System;
7.Automatic Lubrication System;
8.Cooling System;
9.Full Cover (Security Guard Door);
10.Accesssories Tools and Tool Box
11.Wheel Curve Optimize Software

Services:

1-After-sales services: Warranty is one year; we would offer the parts (quality problem) free of charge during this period, freight collect.
2-Alloy Wheel Refurbishemnt Advice from REAL WORLD experts in the Diamond Cutting and Alloy Wheel Refurbishment industry
3-Mechanical Support
4-Software Support
5-Comprehensive Training
6-Probe alloy wheel profile

Just PROBE & Diamond CUT !

Once the machine has automatically probed the wheel profile there is no need for you to waste time programming our Alloy Wheel lathe we have taken care of that for you. Just cut the wheel and store the profile on the system. Build up a library of Alloy wheel profiles.We saved you time so you can cut more wheels!

The machine work steps

1-Probe alloy wheel profile,transformation G code
2-Diamond cut the wheel.
