Atlas Pionjar 120 Similar Petrol Rock Drill Yn27c

Atlas Pionjar 120 Similar Petrol Rock Drill Yn27c
Price: US $ 480-680/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Western Union
Prod Model: YN27C/YN27J
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size: 810*380*280mm
Weight: 45kg
Application: Mining and Quarry ,Concrete Drilling
Color: Yellow
Operation: Hand Held with Gaosline Motor
Feedback: All Clients Give Us Best Feedback
Stock: Enough Stock
Material: Top Quality Parts
Power: Gasoline
Main Market: Euope , Afric,Asia,South and North America.
Structure: Vertical Drilling Machine
Layout: Vertical
Controlling Mode: Artificial
Automatic Grade: Semiautomatic
Precision: High Precision
Number Of Shaft: No

Product Description

Atlas Pionjar 120 Similar Petrol Rock Drill Yn27c
Products Features:
The Internal Combustion Rock Drill Type YN27C is a very efficient machine with the haracters that the structure is very compact, Less of the-easy-to-damage-parts, and very easy to control. It can adapt to these outside situations there is no water and no electronic power. It is a Kind hand held drill built up with gasoline engine, Air pump, rock drill and the rotation plumbum equipment for running or stop. It can be used as a tool for breaking, percussive drilling, tamping besides rock Drilling.

During operation, rock powder is blown away by the compressed air produces by the machine itself. This machine is a portable machine; It is also can use with supporting stand. Drilling hole diameter ¤ 28mm-42mm, when turning vertically down-ward, it can drill to the depth of 6m.

Why Choose Us?

Xiamen Bestlink Factory Co., Ltd since 2000 is committed to providing the best drilling and cutting machine, tools and accessories products in marble and granite stone quarrying, as well as in civil engineering application, especial demolition project. It is now a leading manufacturer of cutting and drilling equipment for the extraction of marble, granite and ornamental stones in china.

Most of our products are of our own proprietary intellectual property rights, such as Pneumatic mobile rock drill, DTH driller, Hydraulic splitting machine, Hydraulic stone stamping machine, Mushroom stone machine.
                 Rock Drill Type         YN27C
Weight(kg)45
Overall dimension(L*W*H) (mm)810*380*280
Diameter of engine piston(mm)Φ58
Stroke of engine piston(mm)70
Rotating speed of engine(r/min)≥2450
Rotating speed of drilling rod(r/min)≥250
Oil consumption(L/m)≤0.12
Tank capacity(liter)1.65
Max.drilling depth(m)6
Shank size(mm)Hex 22x108
Ignition systemcontrollable silicon,
contactless system

Product photos





Xiamen Bestlink Factory Co., Ltd.Is committed to providing the best drilling and cutting machines, tools and accessories products in marble and granite stone quarrying, as well as in civil engineering application, especial demolition project.Our company is now a leading manufacturer of cutting and drilling equipment for the extraction of marble, granite and ornamental stones in China.

Since 1985, we have produced and supplied high quality Split AG Non-Explosive Demolition Agent to our worldwide customers in the quarrying and demolition industries.

From early 2000, we have made a start in the study and developed the Hydraulic Rocks and Concrete Splitters by patent inventions, and reached a great success in the domestic and overseas market.Now, we are only a producer and exporter just now from China.

In 2004, we developed and produced the patented products:Hydraulic Rock Drill, Stone holes Groover, Stone Crack Expander and Hydraulic Rock Breaker.We offer a vast range of hydraulic and pneumatic drills and machines for diamond wire cutting as well as all kinds of accessories for quarrying activities.

Now, quality products are being exported to more than 45 countries and regions all over the world including the USA and Europe with high reputation.

We are continually looking for ways to develop drilling and cutting technology for quarrying and demolition, and hoping to be the world No.1 company about quality and prices of hydraulic Splitters and Expansive Cement within 5 years.Thank you very much for your support and wish to get your deep interest and be your best partner.
