| Prod Model: |
DM4-W027 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Shank: |
Round Shank or Hex Shank |
| Surface Finishing: |
Bright ,Amber,Tin,Black Oxide |
| Hardness: |
45HRC |
| Application: |
Soft Wood,Playwood and Hardwood |
| Diameter: |
6-40mm |
| Process: |
Ground |
| Cutting Edge: |
Angled Spurs |
| Head: |
Center Point |
Product Description
Product Description
Using an expanded brad point tip with angle spurs and adistinguishable spike,spade bits are a drill bit type use exclusively for drilling large holes through wood.Thery most commonly feature a 1/4 hex shank ,come in a range from 6-38mm in diameter,and can be combined with an extension shank to extend their reach.
* made of high carbon steel or chrome vanadium (crv) with brad point and 2 shouldered cutting spurs.
* centre point enters first; prevents "skating".
* cutting flutes are engineered for optimum chip ejection so drill will not bind and burn out.
* for drilling accurate, splinter-free holes in soft wood, hard wood, plywood and hardboard.
* use in hand drills, electric portable drills, drill presses and lathes.
1.Material:45#Steel .
2.Surface:White Finish.
3.Package:pvc pouch.
| Wood Brad Ponit Drill |
| Process | Material | Surface | Tip |
| 45#C | 60#C | HSS | B&W | White | Tin Coated | Brad ponit with 2 raised lips |
| Rolled | √ | √ |
| √ | √ |
| √ |
| Milled | √ | √ |
| √ | √ |
| √ |
| Ground |
|
| √ | √ | √ | √ | √ |
Product Information
Metric System |
|
| Diameter | Overall Length | Shank Diameter |
| 3 | 60 | 3 |
| 4 | 75 | 4 |
| 5 | 85 | 5 |
| 6 | 90 | 6 |
| 7 | 105 | 7 |
| 8 | 115 | 8 |
| 9 | 120 | 9 |
| 10 | 120 | 10 |
| 11 | 150 | 10 |
| 12 | 150 | 10 |
| 13 | 150 | 10 |
| 14 | 150 | 10 |
| 15 | 150 | 10 |
| 16 | 160 | 10 |
| 17 | 160 | 13 |
| 18 | 160 | 13 |
| 19.0 | 160 | 13 |
| 20.0 | 160 | 13 |
| 21.0 | 160 | 13 |
| 22.0 | 160 | 13 |
| 23.0 | 160 | 13 |
| 24.0 | 160 | 13 |
| 25.0 | 160 | 13 |
| 26.0 | 160 | 13 |
Packing&shipping
Packing:pvc bag,plastic box ,blister card
Shipping
1. TNT/FedEx/DHL/UPS for samples or under 45KG weight goods , Door to Door.
2. By Air or by Sea for batch goods,from airport(seaport) to airport(seaport).
3. Customers specifying freight forwarders or not.
4. Production Time: 3- 7days for samples; 2-3.5 weeks for batch goods
Our company
1) We're a direct manufacturer and 100% export to worldwide(USA, Isrel, Jordan, Iran, Thailand,Duabai, South Africa, Kenya, Egypt, Australia, UK, Spain, Brazil, etc)
2) We have around 15 years producing experience.
3) Our drill product:HSS drill bits, masonry drill, SDS drill,glass&tile drill, step drill, wood flat drill, wood auger bit, wood brad drill, center drill, left hand drill, drill set etc.
4) Above 95% customers will place a formal order after testing the samples.
More information about our products, welcome to visit :http://en.dmcraftools.com/
DANYANG DAMING TOOLS Co., Ltd. is one of the professional manufacturer of drill bits in China,
Now we can provide the following cutting tools:
1. HSS straight shank twist drills:
(DIN338, DIN340, DIN1897, DIN345; ASME B. 94.11M: Jobber length, Taper length, Screw Machine Length, Aircraft Ectension, etc);
2. HSS taper shank drills: ( Rolled, Milled);
3. Masonry drills (Chrome plated, Nickle Plated, Zinc plated);
4. SDS Hammer drills;
5. Wood working series: (Wood working drills, Wood Auger bits);
6. Various kind of drill sets in many different types;
7. TCT saw blades
8. Diamond saw blades
9. HSS Hole Saws;
10. HSS Tapes;
11. All kinds of drill sets.
Therefore, our products are well accepted by many customers from all over the world, mainly in North America, Asia, Europe, MID East, South America and other countries and regions.
For a completive quotation or any further information, please don't hesitate to contact us at any way. Our sales staff will be pleased to assist you with our best.
