North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lock Style:
G
Certification:
Ce, FCC
Suitable Door Thickness:
38~55mm
Service Durability:
More Than 300000 Times
Sub-GHz Frequency:
470~525MHz
Sub-GHz Channels:
220channels Can Be Chosen
One Controller Can Control:
50-100 PCS Locks
Power Supply:
4PCS AA Alkaline Batteries
Use Life:
More Than 15 Years
Weight:
4kg
Material:
Zinc Alloy
Type:
Electronic
Style:
Modern
Shape:
Mortise Door Lock
Part:
Lock
Usage:
Hostel/Hotel/Office
Door Thickness Fits:
38-55mm
Product Description
Technical parameters and environment requirements:
Parameters
Parameters feature and range
Voltage
Power supply
4pcs AA alkaline batteries, DC6V
Low voltage alarm
4.8V
Current
Quiescent state
80uA
Dynamic state
<150mA
Working environment
-20ºC~55ºC; <90%RH
CPU
8 bits low power consumption MCU
Storage>10 years
Event Record
Off-line>1600 Records; Online: All Records
Blacklist
100pcs
Time limited red list
148pcs
Normal red list
364pcs
IC identification
Frequency
13.56MHz
Factory card types
Philips M1-S50/S70; Fudan Micro Card; CPU Card
Identification distance
2~3cm
Function
Support IC card configuring networking parameter, setting password, room information, Authorizing to report the loss of cards, opening or closing door locks
Sub-GHz
frequency
470-525MHz
Information channel
About 220communication channels can be chose
Receiving sensitivity
-95dBm
Transmit Power
+2.5dBm
Power handing peak
10 dBm
RSSI Range
-95 dBm to -10 dBm
Output Impedance
50Ω
communication distance
500m range of visibility
audible and visual indication
buzzer , Red Blue indicator light
Incident
alarm monitoring
Main lock tongue, mechanical key, Drawer switch detection (avoid disturbance)
Low Battery Detection
Battery voltage monitoring
Door location State
Change of door location
Door Lock Switch
Reporting incident records by IC card
Remote Control
Open or close door lock by remote control, authorize or revoke IC card by remote control
performance
Battery Life
7200~8640 hours
mechanical endurance
Drawer cannot be open in the case of anti tongue in the open state
Applicative door thickness
38~55mm;
Drawer lock protection
Drawer cannot be open in the case of anti tongue in the open state
secret key
Double secret keys authentication including systematic secret key and card secret key
Changzhou Bonwin Technology Co., Ltd
Bonwin Technology Co., Ltd, founded in 2003, is located in the south of Yangtze River which is a picturesque place gathering many human talents. Since establishment, Bonwin has been focusing on the development and application of Hotel Room Intelligent Management System, intelligent locks and management software and concentrating on creating high-quality products. For almost 10 years, Bonwin has become the one of the leading manufacturers of hotel management system & intelligent locks in eastern China.
Our main products are:
1. Intelligent door locks: MIFARE card lock, EM card lock, IC card lock, Wireless Networking lock
Our goods are suitable for hotels, residential areas and business buildings
"Customer satisfaction" is our objective. We have established ISO9001 quality control system since 2007. Bonwin always insists on the policy "constantly striving for excellence". "The better the process is controlled, the better the outcome is" is our quality management principle.
Technology and innovation is the engine of Bonwin rapid development. As a high-tech enterprise of Jiangsu province, Bonwin has won more than 20 patents at this field, such as the national patent of invention, patent of utility model, etc., as well as a lot of honors, such as High-tech enterprise of Jiangsu province, ISO9001 quality certificate, security certificate of the Ministry of Public Security, CE certificate, FCC certificate, etc.
"Accurate, timely, careful, in place" is our consistent service standard. Perfect after-sales service is the fundamental guarantee to improve customer satisfaction. For 3 years in succession, clients' satisfactions have remained above 95%.
Bonwin people continue to forge ahead. The selling network has widely covered the whole country of China, and the products also sells good in more than 40 countries and regions from Europe, Asia, the America, Africa, and Oceania. Bonwin locks have serviced more than 7000 star-rated hotels and more than 10000 high-graded sauna/swimming centers.
Bonwin has built a good relationship with some international chain hotels, such as RAMADA, DAYS INN, GLORIA, Howard Johnson, etc. And is a long-term partner of more than 300 five-star hotels in China, for example: Jiangsu Jinling Hotel, Beijing Capital Tourism Jianguo Hotel, Zhejiang World Trade Jun LAN Hotel, , Shanxi Tourism Group, Jiangsu Blue Fast Boat hotel, etc.
In this fast-changing market competition, Bonwin keeps on challenge himself and make positive innovation. His eternal goal and pursuing is to form excellent teams, create national boutiques, and offer sincere services, marching to be a world famous brand!
