| Prod Model: |
1908 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
PDC for Cutter Oil Drill Bit |
Product Description
PDC for Cutter Oil Drill Bit is a kind of diamond and carbide substrate composed of composite material, have the characteristics of high hardness, good wear resistance, widely used in petroleum drilling, geological exploration, coal field drilling bit and machining tools, etc.
Drilling diamond compact class: Suitable for soft to medium hard geological drilling, the impact toughness and high thermal stability, heat resistance temperature can reach 750.
Advantages
1) With feature of high working efficiency, smooth surface
2) Advanced technics and strict process control
4) Long lifespan and stable performance
5) Competitive price and superior quality
6) Excellent service
All of our business is carried out in full compliance with the ISO9001 Certification.
Please contact us if you would like any further information.
| Product Number | Diameter
(D)(mm) | Height
(T) (mm) | Diamond Thickness
(t) (mm) | Diamond
Chamfer
(mm) |
| 1308 | 13.44±0.03 | 8.00±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1313 | 13.44±0.03 | 13.20±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1608 | 15.88/16.00±0.03 | 8.00±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1613 | 15.88/16.00±0.03 | 13.20±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1908 | 19.05±0.05 | 8.00±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1913 | 19.05±0.05 | 13.20±0.10 | 2.30±0.20 | 0.30±0.10 |
| 1916 | 19.05±0.05 | 16.31±0.10 | 2.30±0.20 | 0.30±0.10 |
