Prod Model: |
XY |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Drilling Depth: |
0-200m |
Open Hole Diameter: |
260mm |
Drill Rod Diameter: |
50mm |
Drilling Angle: |
90-75 |
Drill Weight: |
560kg |
Spindle Speed: |
570r/Min |
Hoisting Capacity: |
960kg |
Mud Pump: |
Bw160/Bw200 |
Usage: |
Coal, Ore, Water Well |
Type: |
Core Drilling Rig |
Product Description
Core Drilling Rig and Drilling Machine for Geological Exploration and Mining1. The machine is equipped with crawler chassis device, easy to move and speed fast, the crawler chassis' Material system is very resistent steel mill.
2. Hydraulic oil pressure feed device , improve drilling efficiency.
3. Hydraulic chuck, can complete no-- stopping rotating.
4. Pressure gauge display the condition of bottom drilling hole.
5. Drilling mast controlled by hydraulic cylinder.Improve the efficiency.
Specifications: Drilling depth | m | 100 | 250 | 300 | 600 |
Drilling DI | mm | 300 | 200 | 150 | 75 |
Open hole DI | mm | 300 |
End hole DI | mm | 75 |
Drilling rod | mm | Φ60 |
Drilling angle | | 90°-65° |
Rotary Spindle |
Spindle forward speed | r/min | 30-1050 |
Spindle reverse speed | r/min | 29-137 |
Spindle stroke | mm | 560 |
Spindle inner diameter | mm | 96 |
Spindle lifting capacity | KN | 60 |
Main Winch ( drive hydraulic system) |
Single line lifting speed | m/min | 0-45 |
Hug floodgate belt width | mm | 90 |
Tightrope diameter | mm | 14 |
Hoist single line lifting capacity | KN | 40 |
Roller diameter | mm | 200 |
Roller cubic measure | m | 30 |
Mud pump |
Horizontal Triplex BW-250 mud pump |
Displacement | L/min | 250 |
Work pressure | Mpa | 7 |
Water inlet caliber | mm | 75 |
Water to exit caliber | mm | 50 |
Gear Oil pump |
Duplex gear oil pump CBF-F63/25 |
Front displacement,pressure | | 63mL/r 20Mpa |
Behind displacement,pressure | | 25mL/r 20Mpa |
Drilling rig Power |
Diesel engine | Hp | 4100# 50HP |
Electric motor | KW | Y180L-4 22KW |
