| Prod Model: |
DFQ-150W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Dfq-150 |
| Max. Drilling Depth: |
150m |
| Hole Diameter: |
105mm-203mm |
| Drilling Speed: |
3-5min Per Meter, High Efficiency |
| Power(W): |
Diesel Engine, Good for Outdoor Working |
| Mobile Base: |
Trailer, Crawler, Truck Chassis |
| Rock Hardness: |
F=6~12 |
| Work Pressure: |
1.05-2.0 MPa |
| Air Consumption: |
15~24 M3/Min |
| Deliver Time: |
10 Working Days |
| Usage: |
Water Well |
| Power Type: |
Diesel |
Product Description
1. Fully hydraulic operation;
2. Hydraulic stabilizer legs;
3. Working with both Air compressor and Mud pump, functional and applicable to soft soil ground and hard rock gorund;
4. Can drill up to 100~200m deep per day when rock formation.
Application
Water well,
Borehole drilling,
Blast hole,
Geothermal air-conditioning well
Agricultural irrigation well
Water engineering in mountain and rocky areas
Zhengzhou DEFY offer drilling rigs with different chassis:
1. Trailer mounted drilling rig
2. Tractor mounted drilling rig
3. Crawler mounted drilling rig
4. Truck mounted drilling rig
Remarks:
Our engineer will help to design a complete list of drilling rig and drilling tools, especially according to your project to ensure DIRECT USE. For more details, please kindly send us an inquiry or contact our sales people by instant messenger. Thank you very much. ^_^
Contact Info:
Anne Bai
Mobile: 0086-15136212564
Tel: 0086-371-55819257
| Item | Parameter |
| Drilling caliber | Φ105- 203 mm |
| Max. drilling depth | 1 5 0m |
| Diameter of drill pipe | Φ 73 ,Φ 76 |
| Work pressure | 1.05-2.0 MPa |
| Gas consumption | 15~ 24 m³/min |
| Impacter | DHD3 5 0\3 6 0 |
| Apply to rock hardness | f=6-12 |
| Power | 4 4Kw/2 0 00rpm |
| Gradeability | 25° |
| Walking speed | 0~ 2 Km/h |
| System pressure | 20MPa |
| Rotary torque | 200 0N.m |
