| Prod Model: |
HX |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Prodcut Name: |
Diamond Core Drill Bit |
| Manufacturing Arts: |
Sinter |
| Kind: |
Diamond Wheel |
| Abrasive: |
Diamond |
| Type: |
Glass Drill |
Product Description
We specialize in the manufacture of diamond drills, used for glass, ceramic, stone material, concrete and other drilling.
Diamond grain size: 80 # -100#.
Diameter: 5mm - 100mm.
Dig holes. (use Diameter 6mm bit and thickness 6mm glass)
Type Hole
1. General 1800+
2. Profession 2500+
3. High-grade 4000+
Brief description
1 sharp
2 fast drilling speed
3 less chipping
4 long life
Company profile
Zhecheng Hongxiang Superhard Material Company
Specilizing in synthetic diamond and diamond tools
Synthetic diamond RVD, MBD, SMD, diamond drill bit, diamond grinding wheel, diamond saw blade, polishing wheel, resin bond diamond fickert, polishing pads, polishing paste
Qualification: ISO900, high repitation in domestic and overseas, high-tech
Use glass
Size
Thread shank, cone shank, straight shank
Diameter: 5mm-120mm
Length: 60mm, 65mm, 75mm, 95mm
Market: America, England, Egypt, Singapore, India, France, Spain, Iran, Turkey, Russia, Mexico, Vietam, Poland, South Africa
| Reference Data |
| Shank(S) : 1/2"gas | Height of wark layer
:10mm | Machine:
bench drilling
machine | Usage :
drill glass,ceramic, tile , porcelain, |
|
Total length
:75mm |
Thickness of wall
:1mm |
Effective length
:35mm |
|
| Diameter (MM) |
| 5 | 29 | 53 | 77 |
| 6 | 30 | 54 | 78 |
| 7 | 31 | 55 | 79 |
| 8 | 32 | 56 | 80 |
| 9 | 33 | 57 | 81 |
| 10 | 34 | 58 | 82 |
| 11 | 35 | 59 | 83 |
| 12 | 36 | 60 | 84 |
| 13 | 37 | 61 | 85 |
| 14 | 38 | 62 | 86 |
| 15 | 39 | 63 | 87 |
| 16 | 40 | 64 | 88 |
| 17 | 41 | 65 | 89 |
| 18 | 42 | 66 | 90 |
| 19 | 43 | 67 | 91 |
| 20 | 44 | 68 | 92 |
| 21 | 45 | 69 | 93 |
| 22 | 46 | 70 | 94 |
| 23 | 47 | 71 | 95 |
| 24 | 48 | 72 | 96 |
| 25 | 49 | 73 | 97 |
| 26 | 50 | 74 | 98 |
| 27 | 51 | 75 | 99 |
| 28 | 52 | 76 | 100 |
Zhecheng Hongxiang Superhard Material Co., Ltd. Affiliated with Wanke Group, is a highly professional and experienced manufacturer of synthetic diamond powder & diamond tools in China. We have specialized in this field over 27 Years and always dedicated to the produce the diamond tools in high quality and good service.
Our products include,
Synthetic diamond
Diamond powder
Diamond saw blade
Diamond drill bit
Poly crystalline Diamond composite ( PDC )
PCD wire drawing dies
Diamond glass tools
Diamond polishing pad
Diamond cutting tools
Diamond grinding tools
Diamond wheels
Diamond tools, etc.
Why choose us?
1. Since 1990, with over 27 years diamond tools manufacturer experience.
2. Rich experience in OEM order
3. Advanced production equipment
4. Own design team, can help you custom the packaging
5. Own provincial engineering technology center
6. D&B and ISO9001 Certificates
We are a professional synthetic diamond powder & diamond tools company integrating development, production and sales. Factory located in middle of China-Henan, with more than 124000 square meters. "High quality products, competitive prices, and classic services" is the soul of our business.
Warmly welcome all partners to join us for mutual benefits cooperation.
