| Prod Model: |
diamond saw blade |
Product Description
1 The blade has good sharpness and high efficiency at the process of cutting,meanwhile,it has a long lifespan 2 Good cutting result:smooth cutting,flat surface and even size 3 Stable cutting,narrow cutting gap,stone waste reduction 4 M-Shape segment is easy for diamond opening
| Diameter(mm) | Steel core(mm) | Head size(mm) | No. | Shape | Application |
|---|
| 900 | 5.0 | 24×7.0/6.2×13(15,20) | 64 | Z3T/Z3T-M (conical) | Granite |
| 1000 | 5.0 | 24×7.0/6.2×13(15,20) | 70 | Z3T/Z3T-M (conical) | Granite |
| 1200 | 5.5 | 24×7.4/6.6×13(15,20) | 80 | Z3TZ3T-M (conical) | Granite |
| 1400 | 6.0 | 24×8.0/7.2×13(15,20) | 92 | Z3T/Z3T-M (conical) | Granite |
| 1400 | 6.5 | 24×8.4/7.6×13(15,20) | 92 | Z3T/Z3T-M (conical) | Granite |
| 1600 | 7.2 | 24×9.2/8.4×13(15,20) | 108 | Z3T/Z3T-M (conical) | Granite |
| 1800 | 7.5 | 24×10/9.2×13(15,20) | 120 | Z3T/Z3T-M (conical) | Granite |
| 2000 | 8.0 | 24×11/10×15(20) | 128 | Z3T/Z3T-M (conical) | Granite |
| 2200 | 9.0 | 24×11/10×15(20) | 132 | Z3T/Z3T-M (conical) | Granite |
| 2500 | 9.0 | 24×12/11×20(30) | 140 | Z3T/Z3T-M (conical) | Granite |
| 2700 | 9.0 | 24×12/11×20(30) | 140 | Z3T/Z3T-M (conical) | Granite |
| 3000 | 9.3 | 24×13/12×20(30) | 160 | Z3T/Z3T-M (conical) | Granite |
| 3500 | 9.5 | 24×13.5/12.5×20(30) | 180 | Z3T/Z3T-M (conical) | Granite |
| Diameter(mm) | Steel core(mm) | Head size(mm) | No. | Shape | Application |
|---|
| 400 | 2.6 | 40×3.8/3.4×15(20) | 28 | SPLITTING | Granite |
| 450 | 3.0 | 40×4.2/3.8×15(20) | 32 | SPLITTING | Granite |
| 500 | 3.0 | 40×4.2/3.8×15(20) | 36 | SPLITTING | Granite |
| 550 | 3.6 | 40×5.0/4.4×15(20) | 40 | SPLITTING | Granite |
| 600 | 3.6 | 40×5.0/4.4×15(20) | 42 | SPLITTING | Granite |
| 650 | 4.0 | 40×5.4/4.8×15(20) | 46 | SPLITTING | Granite |
| 700 | 4.0 | 40×5.4/4.8×15(20) | 50 | SPLITTING | Granite |
| 750 | 4.0 | 40×5.4/4.8×15(20) | 54 | SPLITTING | Granite |
| 800 | 4.5 | 40×6.0/5.4×15(20) | 57 | SPLITTING | Granite |
| 850 | 4.5 | 40×6.0/5.4×15(20) | 58 | SPLITTING | Granite |
| Diameter(mm) | Steel core(mm) | Head size(mm) | No. | Shape | Application |
|---|
| 300 | 2.2 | 20×3.2×15(20) | 40 | R20 | Granite |
| 350 | 2.2 | 20×3.2×15(20) | 46 | R20 | Granite |
| 400 | 2.6 | 20×3.6×15(20) | 52 | R20 | Granite |
| 450 | 3.0 | 20×4.0×15(20) | 58 | R20 | Granite |
| Diameter(mm) | Segment Dimension(mm) | Born/mm | No. |
|---|
| 105 | 20×1.8×7.5 | 16,20 22.23 25.4,50 | 8 |
| 115 | 20×1.8×8.0 | 16,20 22.23 25.4,50 | 9 |
| 125 | 20×2.0×8.0 | 16,20 22.23 25.4,50 | 10 |
| 150 | 20×2.0×7.5 | 16,20 22.23 25.4,50 | 10 |
| 180 | 20×2.2×8.0 | 16,20 22.23 25.4,50 | 14 |
| 200 | 20×2.2×8.0 | 16,20 22.23 25.4,50 | 14 |
| 230 | 20×2.4×8.0 | 16,20 22.23 25.4,50 | 16 |
| 250 | 20×2.4×8.0 | 16,20 22.23 25.4,50 | 18 |
| 300 | 20×2.6×8.0 | 16,20 22.23 25.4,50 | 22 |
| 350 | 20×2.8×8.0 | 16,20 22.23 25.4,50 | 24 |
Other specifications are available upon request.
