| Prod Model: |
ZW-INV900-HB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Inv |
| Shape: |
Mortise Door Lock |
| Size: |
245*75mm |
| Color: |
Pb-Golden, Ab-Bronze, Hb-Red, Ss-Silver |
| Finished: |
Chrome Plated |
| Suitable For: |
Home Door |
| Customized: |
Customized |
| Type: |
Fingerprint |
| Design: |
Touch Screen |
| Usage: |
Industrial |
| Material: |
Alloy |
Product Description
Features
- Modern design, fashion and beautiful, four color available
- American standard five latch lock body
- Anti-theft locks with three-way and five bolts design, superior security
- Imported NXP MCU and main components, humidity-proof SMT process
- Easy to install and set up with LED indicator
- Free rotating handle
- Suport four type of unlocking way: Fingerprint, ID/Mifare 1 Card, Remote Control or Mechanical Key;
- Ideal for Residential / Commercial applications
Technical Parameter:
-Fingerprint Parameters:
* Fingerprint reader: Live fingerprint(AUTO Power, no buttons)
* Finger placing angle: 360º
* True rejection rate: <0.1%
* Flase acceptance rate: <0.001%
* FP memory capacity: 100pcs
* Reading time: <1s
-RF Card Parameters:
* Card type: ID/Mifare 1 Card
* Frequency: 125HKz(T5557/ EM4305/ RFID)~13.56MHz(Mifare 1)
-Environment Paramenters:
* Relative Humidity: 20% ~ 90%
* Temperature: -20 ~ +50 º C
-Power Parameters:
* Power Consumption: Static standby< 15μ A; Dynamic< 120mA
* Battery Lifes: 4PC AA batteries, over 8000 times unlock
* Backup power: DC 9V
* Low Voltage: Alert 4.8V, allow 200 times when alert
-Other Parameters:
* Door thickness required: 38-70mm (Can be customized)
* Unlocking ID record: No support
