| Prod Model: |
4mm-45mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Classification: |
Hammer Drill |
| Drill Brand: |
LC&Yc |
| Applications: |
Building and Industrial |
| Impact Drill Structure: |
Ball-Type |
| Impact Drill Head: |
Impact Drill |
| Drill Shape: |
Round |
| Condition: |
New |
Product Description
SDS PLUS Drill Bits. Impact-resistant and bend-resistant drill bit, guarantees longer life.
. Wide and deeply supported plate prevents the tip from breaking out.
. High-temperature-brazed tungsten carbide blades for fast, accurate and safe drilling.
. Large volume spiral flute enables optimum drilling dust removal.
. Low vibration guarantees fatigue-free working.
. Suitable for drilling holes in granite, concrete, masonry, limestone, natural and artificial stone and so on.
With professional technology, experience, and competitive prices, our products are more and more popular in the word, especially in America, Europe, Middle East, India, Indonesia etc.
No matter the order quantity is big or small, we always do our best for our customers at any time. Hope to cooperate with you for long times with firm relationships.
Manufacturing Process: Milled.
Body material: 40Cr, Tip carbide material: YG8.
Shank: SDS plus, SDS max, hex, spline
Flute: Double, single
Tip feature: Flat, cross, W, three
Surface treatment: White finish, Sandblast finish.
Packing: Plastic bag, Plastic tube, Hanger, Skin card
Diameter: 4-45mm
Length: 110-1000mm
Use for: For drilling stone, brick, concrete, marble, granite etc.
The drill body of carbide alloy electric hammer drill employs high grade ally steel. The drill tip is welded with YG carbide alloy. It can be used with various types of electric hammer and it is a widely applicable and high efficient drilling tool for construction or installation trade.
SDS Plus drill bits can be used with Electric Hammer of BOSCH Co., of AFG Co., of HILTI Co.., of HITACHIKOKL Co., of Toshiba Co., The shank is round with Dualarc dual keyway
| Diameter x Overall Length | Working Code Length | Diameter x Overall Length | Working Code Length |
| 4.0 x 110mm | 45mm | 13.0 x 160mm | 80mm |
| 4.0 x 160mm | 95mm | 13.0 x 210mm | 130mm |
| 5.0 x 110mm | 45mm | 13.0 x 260mm | 180mm |
| 5.0 x 160mm | 95mm | 13.0 x 300mm | 220mm |
| 5.0 x 210mm | 147mm | 13.0 x 460mm | 380mm |
| 5.0 x 310mm | 247mm | 14.0 x 160mm | 80mm |
| 5.5 x 110mm | 45mm | 14.0 x 200mm | 120mm |
| 5.5 x 160mm | 95mm | 14.0 x 260mm | 180mm |
| 5.5 x 210mm | 147mm | 14.0 x 300mm | 220mm |
| 5.5 x 260mm | 197mm | 14.0 x 460mm | 380mm |
| 5.5 x 310mm | 247mm | 14.0 x 600mm | 520mm |
| 6.0 x 110mm | 45mm | 14.0 x 1000mm | 920mm |
| 6.0 x 160mm | 97mm | 15.0 x 160mm | 80mm |
| 6.0 x 210mm | 147mm | 15.0 x 200mm | 120mm |
| 6.0 x 260mm | 197mm | 15.0 x 260mm | 180mm |
| 6.0 x 460mm | 397mm | 15.0 x 460mm | 380mm |
| 6.5 x 110mm | 45mm | 16.0 x 160mm | 80mm |
| 6.5 x 160mm | 97mm | 16.0 x 200mm | 120mm |
| 6.5 x 210mm | 147mm | 16.0 x 250mm | 180mm |
| 6.5 x 260mm | 197mm | 16.0 x 300mm | 230mm |
| 7.0 x 110mm | 45mm | 16.0 x 460mm | 380mm |
| 7.0 x 160mm | 97mm | 16.0 x 600mm | 520mm |
| 7.0 x 210mm | 147mm | 16.0 x 800mm | 720mm |
| 8.0 x 110mm | 45mm | 16.0 x 1000mm | 920mm |
| 8.0 x 160mm | 97mm | 17.0 x 200mm | 120mm |
| 8.0 x 210mm | 147mm | 18.0 x 200mm | 120mm |
| 8.0 x 260mm | 197mm | 18.0 x 250mm | 175mm |
| 8.0 x 310mm | 247mm | 18.0 x 300mm | 220mm |
| 8.0 x 460mm | 397mm | 18.0 x 460mm | 380mm |
| 8.0 x 610mm | 545mm | 18.0 x 600mm | 520mm |
| 9.0 x 160mm | 97mm | 18.0 x 1000mm | 920mm |
| 9.0 x 210mm | 147mm | 19.0 x 200mm | 120mm |
| 10.0 x 110mm | 45mm | 19.0 x 460mm | 380mm |
| 10.0 x 160mm | 97mm | 20.0 x 200mm | 120mm |
| 10.0 x 210mm | 147mm | 20.0 x 300mm | 220mm |
| 10.0 x 260mm | 197mm | 20.0 x 460mm | 380mm |
| 10.0 x 310mm | 247mm | 20.0 x 600mm | 520mm |
| 10.0 x 360mm | 297mm | 20.0 x 1000mm | 920mm |
| 10.0 x 460mm | 397mm | 22.0 x 250mm | 175mm |
| 10.0 x 600mm | 537mm | 22.0 x 450mm | 370mm |
| 10.0 x 1000mm | 937mm | 22.0 x 600mm | 520mm |
| 11.0 x 160mm | 95mm | 22.0 x 1000mm | 920mm |
| 11.0 x 210mm | 145mm | 24.0 x 250mm | 175mm |
| 11.0 x 260mm | 195mm | 24.0 x 450mm | 370mm |
| 11.0 x 300mm | 235mm | 25.0 x 250mm | 175mm |
| 12.0 x 160mm | 85mm | 25.0 x 450mm | 370mm |
| 12.0 x 210mm | 135mm | 25.0 x 600mm | 520mm |
| 12.0 x 260mm | 185mm | 25.0 x 1000mm | 920mm |
| 12.0 x 310mm | 235mm | 26.0 x 250mm | 175mm |
| 12.0 x 460mm | 385mm | 26.0 x 450mm | 370mm |
| 12.0 x 600mm | 525mm | 28.0 x 450mm | 370mm |
| 12.0 x 1000mm | 920mm | 30.0 x 460mm | 380mm |
Customer questions & answers
Q: What's your MOQ?
A: Our MOQ is 100pcs for small sizes (dia.4mm-16mm, length 110mm-310mm), 50pcs or 20 pcs for big sizes (dia. 17mm-45mm, length 360mm - 1000mm).
Q: What's your payment terms?
A: We can do the below payment terms as below:
1. Order amount ≤ USD 3000, we do the payment term: T/T 100% in advance.
2. Order amount ≥USD 3000 and ≤USD 20000, we do the payment term: T/T 20% in advance, the balance 70% will be paid against the copy of B/L after shipment.
3. Order amount ≥ USD 20000, we can do L/C at sight.
4. Some customer do business with us for long time and good reputation, we can do D/P at sight.
Q: What's the delivery time?
A: 30-45 days.
Q: Can I get free samples?
A: Yes, we could provide free samples and deliver with freight collected.
If you interest our products and want to know more informations about our products, please contact with me:
My name: Jocelyn
Mobile: 0086-13429197640
Office Phone: 0086-0571-89360992
Office Fax: 0086-0571-88303757
Hangzhou Lichang Tools Co., Ltd previously known as Whenzhou Yongchang Tools which is set up in 1987, ithas awarded the ISO9002 Certificate. Lichang specialized in the production of various tooling productssuch as SDS-plus electric hammer drill bits, HSS twist drills, chisels, carbide tipped router bits, hole drilling implements, TCT saw blades and some other power tool accessories.
Thanks to unlimited experience, excellent faxilities as well as advanced technology, the quality of our products ranks among the best in our domestic market. While our products are distributed nationally in China. We have many very satisfied customers internationally, including customers in Europe and the U. S. A...
No matter how big your order is we will always offer the most competitive prices and the kbest service possible. We would like our business relationship to be mutually beneficial as we continue to grow business together.
We thank all our clients for their loyal support!
