| Prod Model: |
OPT-048-010 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cell Type: |
Cylindrical LiFePO4 Battery 3.2V-5000mAh |
| Battery Size: |
320*180*79mm or Customized |
| Cut-off Voltage: |
40V |
| Max Charge Volatage: |
58.4V |
| Standard Charge Current (a): |
0.2c(2A) |
| Charge Method: |
Cc/CV |
| Standard Charge Time(Hours): |
5-6 |
| Rated Voltage: |
51.2V |
| Battery Model: |
LiFePO4 Battery 48V 10ah |
| Long Life Cycle: |
More Than 2000times |
| Type: |
Lithium-Ion Battery Pack |
| Connection Mode: |
Series and Parallel |
| Usage: |
Electric Bicycles and Electric Bike |
| Standard Voltage: |
48V/51.2V |
| Rated Capacity: |
10ah |
| Electrolyte: |
LiFePO4 |
Product Description
Electric bike and Electric bicycle lifepo4 battery 48V 10Ah| Normal performance |
| No | Item | General Parameter |
| 1 | Cell Model(Single cell) | IFR32650 |
| 2 | Standard Capacity | 10Ah |
| 3 | Rated Voltage | 48V /51.2V |
| 4 | Max.Charge Voltage | 54.8V/58.4V |
| 5 | Cut-off Voltage | 37.5V/40V |
| 6 | Standard Charge Current | 2A |
| 7 | Standard Charging Time | 5h |
| 8 | Dimensions | customized |
| 9 | Total Weight(Approx.) | About 6 kg |
| 10 | Impedance(Max, at 1000Hz.) | ≤ 50mΩ |
-- Features--
1) Long cycle life: more than 2000 times (charge and discharge at 1C, 99% DOD).
2) High safety: no fire and explosion in overcharge test . The highest temperature <150°C.
3) Good charging and discharging performance.
(A)0.2C5A ≥100% (B)1C5A ≥99% ( C)2.5C5A ≥97%
4) High discharge rate up to 10C.
5) Environmental-friendly: all raw material of the batteries are environmental-friendly.
6) Wide working temperature range: -25°C to 60°C.
--Application--
1.Vehicles: electric bicycle, golf car, electric wheelchair, electric scooter
2.Illuminate devices: solar battery, miner lamp, solar street lamp, emergency light, electric torch, wind and solar system
3.Communication: back-up electric supply, interphone
4.Power tools: electric cropper, electric drill, electric saw, electric hammer,pump
5.Others: RC toy, small home appliance.
--Service by us--
1.Give you the specific battery pack within 24hours according to your requirements.
2.Professional:Professional technicians offer overall systematic service.
3.One-stop battery solution with battery cells, BMS, case and matching charger.
4.Beyond customer demand: To think more for customer, do better for customer and make customer more satisfied.
5.MOQ:1 unit is ok for your first battery pack to be tested.
6.Warranty:1years
--About Optimum Battery Co., Ltd.--
1. The approved supplier of Universiade Shenzhen 2011, their 80% lithium battery offered by us.
2. As the professional and leading LiFePO4 battery manufacturer in China, we have a capacity of 1.25 MWh per day.
3. Established in 2001, Optimum Battery Co., Ltd is high-tech corporation with independent intellectual-property and core technologies, which is specialized in LiFePO4 and NI-ZN battery's R & D, production and management. Adjacent to Shenzhen Grand Industrial Park, and with an occupation about 20, 000 square meters, we have more than 1000 employees and over 50 senior engineers.
--Why do you choose us?--
1.Quick response to clients' enquiries within 24hrs
2.Tailor-made solution provided by our experienced team and professional engineers.
3.More than 12 years experience in producing battery products for various application.
4.Value quality and long-term cooperation to reach win-win relationship.
5.Quality System: ISO14001,ISO9001, TS16949,SGS
Certifications: UL, ETL, CE, RoHS, UN38.3,MSDS
