| Price: | US $ 1000-3000set |
|---|---|
| Min Order: | 1set |
| Pay Type: | L/C,T/T,Western Union,Paypal |
| Prod Model: | BH 600 |
|---|---|
| Application: | Wood Shaving Machine for Animal Bedding |
| Model: | Bh-400 Pine Wood Shaving Machine |
| Power: | 11kw |
| Output: | 300kg/Hour |
| Blades: | 4 PCS |
| Feed Inlet Size: | 130 X 100 mm |
| Keyword 4: | Wood Shaving Grinder |
| Keywords 1: | Wood Shaving Machine |
| Keywords 2: | Wood Shaving Mill |
| Keywords 3: | Wood Shavings Making Machine |
| Object: | Wood |
| Drive: | Electric |
| Crushing Style: | Grinding and Impact |
| Cutter Material: | High-Speed Steel |
| Finished Surface: | Outer Surface Process |
| Compressive Strength (',For Crushing): | 250-300MPA |
| Type: | Wood Shaving Grinder |
| Crushing Degree: | Wood Shaving Grinder |
| Principle: | Wood Shaving Grinder |
| Tongs' Features: | Wood Shaving Grinder |
| Model | Capacity (kg/h) | Motor (kw) | Weight (kg) | Blade Q'ty | Inlet size (mm) |
| BH - 400 | 200~300 | 7.5-11 | 200 | 4 pcs | 130 x 100 |
| BH - 600 | 400~600 | 15-18.5 | 380 | 4 pcs | 150 x 200 |
| BH - 800 | 800~1200 | 30-37 | 850 | 8 pcs | 230 x 250 |
| BH - 1200 | 1500~1800 | 55 | 1150 | 9 pcs | 290 x 400 |
| BH - 1500 | 2000~3000 | 75 | 1600 | 12 pcs | 330 x 450 |
The log or tree branches enter to the shaving machine from feeder, then after the cutting by the inner cutters,so we can get the shavings. The shaving is uniform in size, thickness.
The shaving can be used as the raw materials of shaving board, and the material of wood pulp paper in paper industry, the packing bed in transportation for fragile goods, as well as the soft sleeping bed for pig, cattle, sheep and other animals.
Structure of disc wood shaving machine:
This electric wood shaving machine includes machine frame, platform on the frame, knife rest fixed on
the platform, electrical box supply the power to the shaving machine, timber pressing device and timber round movementdevice.
The timber pressing device compress the timber tightly onto the platform through air cylinder, the timber round movement device is installed onto the timber's slipway through driving of hydraulic cylinder,
then this device moves shuttling along the platform, the the shaving knife produce the wood shavings.
Suitable raw material for wood shavings (for animal bedding)
Saw dust • Wood Chips • Wood logs • Tree branch • Wheat Straw • Peanut-shell • Rice husk •
Sugar Cane Bagasse • Coffee Husk • Paddy Straw • Sunflower Seed Husk • Sunflower Stalk •
Reeds • Cotton plant Stem • Tobacco waste • Mustard Stalk • Jute waste • Bamboo Dust • Tea waste • Palm husk • Soybeans husk and many other agro and forest wastes, which size is about 30mm.
