| Prod Model: |
BL-BL-J4B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max. Swing Dia. Over Bed: |
350mm |
| Max. Swing Dia. Over Cross Slide: |
215mm |
| Max. Swing Dia. In Gap: |
485mm |
| Guideway Width: |
182mm |
| Max. Machining Length: |
940mm |
| Spindle Bore: |
38mm |
| Main Motor Power: |
1.1kw(1.5HP) |
| Coolant Pump Power: |
0.04kw |
| Net/Gross Weight: |
395/445kg |
| Foot Stands(Net/Gross Weight): |
60/65kg |
| Type: |
Horizontal Lathe |
| Power Source: |
Electric |
| Controlling Mode: |
Artificial |
| Automatic Grade: |
Semiautomatic |
| Setting Mode: |
Floor-type |
| Precision: |
High Precision |
| Processing Accessory: |
Chuck |
| Tool Holder: |
One |
Product Description
Gap Bed Lathe (BL-BL-J4B)(Cam-lock)
Feature:
Engineered from High Grade Castings
'V' Way Bedways luduction hardened and Ground
Gap bed
Cross and longitudinal interlocking feed, enough safety
ASA D4 camlock spindle nose
Various thread cutting function
Standard Accessories:
Tool post wrench
Double-end wrench
Allen wrench
Screw driver
Center
Center sleeve
Change gears
Oil gun
Tool box
Steady rest(Already set in)
Follow rest(Already set in)
3-jaw chuck(Already set in)
Optional Accessories:
Drilling chuck
Drilling chuck
Live center
Face plate
Foot brake
Lead screw guard
Working lamp(Common)
Working lamp(Aluminium rind)
Coolant system
Taper attachment
2 speed motor system
| Item | BL-BL-J4B |
| Max. Swing Dia. Over bed | 350mm |
| Max. Swing Dia. Over cross slide | 215mm |
| Max. Swing Dia. In gap | 485mm |
| Guideway width | 182mm |
| Max. Machining length | 940mm |
| Spindle bore taper | MT5# |
| Spindle bore | 38mm |
| Step of spindle speed | 9kinds |
| Range of spindle speed | 64~1500rpm |
| Spindle nose | D1-4 |
| Metric thread | 26kinds(0.4~7 mm) |
| Inch thread | 34kinds(4~56TPI) |
| Range of longitudinal feeds | 0.052~1.392mm/r |
| Range of cross feeds | 0.014~0.38mm/r |
| Dia. Of lead screw | 22mm |
| Pitch of lead screw | 3mm or 8TPI |
| Max. travel of saddle | 810mm |
| Max. travel of cross | 150mm |
| Max. travel of tool post | 90mm |
| Max. travel of tailstock sleeve | 100mm |
| Tailstock sleeve Dia. | 32mm |
| Tailstock sleeve taper | MT3# |
| Main motor power | 1.1kw(1.5HP) |
| Coolant pump power | 0.04kw(0.055HP) |
| Overall dimension | 1780×750×760mm |
| Left foot stand(L*W*H) | 400×370×700mm |
| Right foot stand(L*W*H) | 300×370×700mm |
| Net/Gross weight | 395/445kg |
| Foot stands(Net/Gross weight) | 60/65Kg |
