| Prod Model: |
FOX outdoor p10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size Of Modual: |
160mm X 160 mm |
| Module Size: |
160*160mm |
| Density Of Pixel: |
10000dots/M2 |
| Best Viewing Distance: |
10-150 |
| Horizontal Viewing Angle: |
120 |
| Color Temperature: |
6500k |
| Frame Frequency: |
60Hz |
| Brightness: |
7000nits |
| Life Span: |
> 100, 000 Hours |
| Mtbf: |
>10,000 Hours |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
10mm |
| Display Function: |
Video Display |
| Pixel Density: |
10000 dot / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
CCC |
| Pixel Configuration: |
1r1g1b, 1R, 1G, 1B |
| Average Power Consumption: |
<=800W/Sqm |
Product Description
HD Full Color Screen P10 Outdoor Rental LED Display
1. UL, CE&RoHS
2. HD high resolution
3. Uniform color, good after sale-sevice
4. waterproof ip65
5. Warranty 5years
| | The technology parameter of P 10outdoor |
| Number | Item | P10 |
| 1 | Pixel pitch | 10mm |
| 2 | Size of modual | 160mm X 160 mm |
| 3 | Resolution of modual | 16*16 |
| 4 | Density of pixel | 10000dots/m2 |
| 5 | Pixel configuration | 1R1G1B |
| 6 | Red wavelength | 625± 2nm |
| 7 | Green wavelength | 525± 2nm |
| 8 | Blue wavelength | 470± 2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 8-150m |
| 11 | Horizontal viewing angle | 120° |
| 12 | Maximum power consumption | ≤ 800W/m 2 |
| 13 | Brightness | ≥ 7000cd /m 2 |
| 14 | Gray scale | 16bits per color |
| 15 | Color temperature | 6500k |
| 16 | Control method | Synchronization & Asynchronization |
| 17 | Driving method | constant scanning |
| 18 | Frame frequency | 60Hz |
| 19 | Refresh frequency | ≥ 300Hz |
| 20 | Working voltage | AC220V/110V± 10% |
| 21 | IP grade | IP65 |
| 22 | Working temperature | -20° C~80° C |
| 23 | MTBF | > 10000 hours |
| 24 | Life span | > 100, 000 hours |
| 25 | Defects rate. | ≤ 0.00001(Led display line standard< 0.0001) |
| 26 | Computer operation system | Win XP/Vista/ Win 2000/WIN7ect. |
| 27 | Video signal | RF, S-Video, RGB, RGBHV, YUV, YC. ect |
| 1. Dust-proof: High-temperature spray technology: can greatly increase the capability of rust-proof. |
| 2. Moudle planeness: ≤ ± 0.2mm |
| 3. Super uniformity in color. |
| 4. Long life-span. Use wave soldering technology for circuit board, prevent from humidity and oxidation, can extend its use life. |
| 5...Energy-saving. Use high efficiency switching power supply, reduce failure rate of power supply. |
| 6. Silicagel is filled and embedded on the front face of the display module, and the all-door structural design protects the LED display from water, dust, and corrosion, antifreeze. |
| 7. Passed IP67 waterproof and dustproof test. |
| 8. High reliability. Flexible to work under different climate condition, can work normally in all harsh environment, such as strong wind, sandstorm, high temperature, low temperature, dryness, rainstorm, and so on. |
Our service:
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year.
During this time, we will replace or remend our goods for free
if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materils only.
2. Technology Training
(1) We provide the technology training for free,
which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consulation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consulation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free
and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information,and some other information
such as flight box, structure information for your reference for free.
