| Prod Model: |
HZ-HCB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Segment Dimension(L*W*H): |
40*5*10mm |
| Segment Numbers: |
28PCS |
| Welding: |
High Frequency Welding |
| Slot Type: |
U Slot |
| Saw Blank Material: |
Manganese Steel |
| Apply For: |
for Marble Cutting |
| Business Type: |
Manufacturer |
| Quality Certifications: |
ISO 9001-2000;SGS |
| Customized: |
Customized |
Product Description
High efficiency 400mm horizontal diamond saw blade for marble cutting:
1.Segment size:40*5*10mm
2.Segment numbers:28pcs
3.Inner core:50mm or can be design according to your requirement.
4.Horizontal blade.
5.Usage:for marble cutting.Please tell us the rigidity of the marble you want to cut(or send us the image of stone is ok) and other requirements,our engineer will design the right products for you.Thanks.
Our advantages:
1.Enough sharpness and good cutting result.
2.Affordable,sharp and wear resisting.
3.Rich experience:more than 20 years' experience in research,development and stone cutting.
4.High sharpness:Our marble diamond segment is positioning in higher cutting efficiency.adjust lifespan according to their needs on the basis of enough sharpness.
5.Stable quality:spirit of striving for perfection,precisive fine training management,as well as stable and high professional produce team can make sure our products keep better quality stability.
Marble Diamond saw blade parameters:
Diameter (mm) |
Segment dimension L*W*H |
Core thickness
(mm) |
Segment number
(pcs) |
300 |
40*3.2*8(10)&40/42*3.2*8(10) |
1.8/2.2/2.4 |
22 |
350 |
40*3.4*8(10)&40/42*3.4*8(10) |
1.8/2.2/2.4 |
25 |
400 |
40*3.6*8(10)&40/42*3.6*8(10) |
1.8/2.6/2.8 |
29 |
450 |
40*4.4*8(10) |
2.2/2.8/3.3 |
33 |
500 |
40*5.5*8(10) |
3.0/3.3 |
36 |
550 |
40*5.0*8(10) |
3.0/3.5 |
40 |
600/625 |
40*6.0*8(10) |
3.0/3.6 |
42 |
700/725 |
40*6.5*8(10) |
3.6/4.0 |
46 |
800/825 |
40*6.5*8(10) |
4.5/5.0 |
46 |
900 |
30*8*10 |
5.0 |
64 |
Other specifications are available upon request.
Company Introduction:
Huazuan Diamond Tools is a company like no other. Customers join the Huazuan team year after year knowing it's owner and employees care about the customer and the selection process of buying diamond tools. Our staff is compiled of experts in the field ready and enthusiastic to work with you and answer any questions you may have along the way.
Founded in 1994 Huazuan Diamond Tools has become one of the leading manufactures of diamond segments and diamond blades. Using the latest cutting technology for hot pressed, cold pressed, vacuum brazed and laser welded diamond blades. Also has other products with stable performance like diamond wire saw, core drill bit and grinding polishing tools. Quality is always our uppermost priority and already been vertified in different markets.
FAQ
Q:Which design is best for you?
A:Considering to cut different objects,there are a lot of diamond blades with different thickness,size,materialproportion,design and technology.You need to teel us what you will cut,its hardness,thickness,sharp,the speed you need.Then our engineer will design the right blade for you.
Q: Which grade is suitable for you?
A: We have economical ones and pro ones,please tell us your target price and the market you will sell.Then we will analyze and provide you the best price for you.
Q: Blade with or without sound attenuation?
Tell us if your country has the laws that don't allow so much noise or not,then we will arrange well for you.
