High Quality Double Acting Hydraulic Cylinder for Large Machine

Name: High Quality Double Acting Hydraulic Cylinder for Large Machine
Brand: tool-buy.com
SKU: 823324565
Availability: InStock
Rating: 4.9 (70 reviews)

Price:	US $ 100-3000/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Jiangsu Canete Machinery Manufacturing Co., Ltd.

Showroom Product Company Profile

Prod Model:	KET-RR
Name:	Double Acting Hydraulic Cylinder
OEM:	Yes
Working Pressure:	70MPa
Color:	Can Customer
Closed Height:	196-1644mm
Warranty:	One Year
Weight(Kg):	12-1224
Extended Height(mm):	253-2863
Max Load(Kn) Pull:	33-2838
Max Load(Kn) Push:	101-5108
Type:	Hydraulic Jack
Structure:	Hydraulic Jack
Power Source:	Hydraulic
Capacity (',Load):	10-520t
Max Height:	57-1220mm

Product Description

Product Description
KIET Brand Double Acting High Tonnage Pull Hydraulic Cylinder

Features
Collar threads, plunger threads and base mounting holes for easy fixturing (on most models)
Baked enamel finish for increased corrosion resistance
Removable hardened saddles protect plunger during lifting and pressing
Built-in safety valve prevents accidental over-pressurization
CR-400 couplers included on all cylinder models
Plunger wiper reduces contamination, extending cylinder life

Applications
Welding and lifting of ship hull
Equipment maintenance and lifting in steel plant
Equipment maintenance and lifting in thermal power plant
Maintenance and sychronous lifting of ancient building
Eqiupped with a variety of hydraulic tools to bending, cutting, pumching, pressing and so on

Our Service:
KIET provide one year guarantee for all the hydraulic tools. We promise if there is any dysfunction of the hydraulic tools during the quality warranty not by outside force, we will replace a new one for free. Any quality defects reported by customers will be responded in 24 hours.

Packaging & Shipping:

We provide wooden packing for each cylinder, which can perfectly protect, the shipping can be by express parcel, by air or by sea shipping.
Company Information:

Jiangsu Canete Machinery Manufacturing Co., Ltd. Is a manufacturer engaged in design and manufacturing hydraulic cylinders (capacity covers from 10- 1000 tons), synchronous PLC hydraulic system, hydraulic pumps, hydraulic torque wrenches, and electric torque wrenches, and hydraulic components.
We successfully transformed from OEM manufacturer for Enerpac, Titan, to create our own brand KIET, and our factory has been approved by CE, ISO9001: 2008 consecutively.

Our customers includes many big Chinese industrial companies, such as China Petroleum, Baosteel, Sinopec, China State Grid, Jiangnan Shipyards, Sany Group, China Railway Construction Corporation. Our synchronous PLC hydraulic system had played a great role in the China high-speed railway constructions. In 2011, our sales revenue reached 30 million USD, making us one of the leaders in the Chinese hydraulic cylinders market especially in the extra-high hydraulic cylinders for industrial area and construction field.
We are a manufacturer in Hydraulic tools, such as:
Hydraulic cylinders, jacks (5-1000ton), single acting and double acting, hollow plunger;
Hydraulic/ electric /pneumatic torque wrench (100-72000Nm);
Hydraulic bolt tensioner (100-11486NM); Hydraulic pullers (5-100 ton)
Hydraulic pumps, manual and electric type (max up to 3000bar);
Integrated hydraulic lifting system solutions ( 4-72 points lifting system for house translation or leveling, bridge supporting and tank welding supporting)
Hydraulic nut and couplings. (M50-Tr1000)

More Information and questions please feel free to contact me:
Aaron
Mobile: +86 18052610078
Office: +86 523-86183388
Hydraulic Tools Manufacturing Leader !
Jiangsu Canete Machinery Manufacturing Co.,Ltd
Factory: No.199 , JingEr Road Economic Development Zone, Taizhou City, Jiangsu of China
Website: www.kaientehydraulic.com

Welcome to Our Company!

Model Number	Cylinder Capacity	Stroke	Maximum Cylinder Capacity		Cylinder Effective Area		Oil Capacity		Collapsed Height	Extended Height	Outside Diameter	Weight
	(tons)	(in)	(ton)		(in2)		(in3)		Collapsed Height	Extended Height	Outside Diameter	Weight
	(tons)	(in)	Push	Pull	Push	Pull	Push	Pull	(in)	(in)	(in)	(lbs)
KET-RR-1010*	10	10.00	11.1	4.0	2.23	0.80	22.33	8.00	16.13	26.13	2.88	28
KET-RR-1012*	10	12.00	11.1	4.0	2.23	0.80	26.80	9.00	18.00	30.00	2.88	31
KET-RR-308*	30	8.25	32.5	6.0	6.51	3.00	53.67	25.00	15.25	23.50	4.00	40
KET-RR-3014*	30	14.50	32.5	6.0	6.51	3.00	92.70	43.00	21.63	36.13	4.00	64
KET-RR-506	50	6.13	55.3	11.8	11.06	3.40	67.77	21.00	13.06	19.19	5.00	67
KET-RR-5013		13.13	55.3	11.8	11.06	3.40	145.17	44.00	20.06	33.19	5.00	115
KET-RR-5020		20.13	55.3	11.8	11.06	3.40	222.56	68.00	28.88	49.00	5.00	150
KET-RR-756	75	6.13	79.6	17.6	15.92	4.90	97.58	29.00	13.69	19.81	5.75	92
KET-RR-7513	75	13.13	79.6	17.6	15.92	4.90	209.00	64.00	20.69	33.81	5.75	150
KET-RR-1006	100	6.63	103.2	48.0	20.65	9.60	136.93	63.00	14.06	20.69	7.00	135
KET-RR-10013		13.13	103.2	48.0	20.65	9.60	271.17	126.00	20.63	33.75	7.00	205
KET-RR-10018		18.13	103.2	48.0	20.65	9.60	374.44	174.00	27.06	45.19	7.00	260
KET-RR-1502	150	2.25	153.5	74.0	30.71	14.80	69.11	33.00	7.72	9.44	8.00	110
KET-RR-1506		6.13	153.5	74.0	30.71	14.80	188.28	91.00	15.19	21.31	8.00	205
KET-RR-15013		13.13	153.5	74.0	30.71	14.80	403.27	194.00	22.20	35.31	8.00	275
KET-RR-15032		32.13	153.5	74.0	30.71	14.80	986.84	475.00	43.94	76.06	8.00	525
KET-RR-2006	200	6.00	221.0	112.5	44.21	22.50	265.28	135.00	16.94	22.94	9.75	325
KET-RR-20013		13.00	221.0	112.5	44.21	22.50	574.78	293.00	23.94	36.94	9.75	440
KET-RR-20018		18.00	221.0	112.5	44.21	22.50	795.85	396.00	30.13	48.13	9.75	450
KET-RR-20024		24.00	221.0	112.5	44.21	22.50	1061.00	528.00	36.13	60.13	9.75	616
KET-RR-20036		36.00	221.0	112.5	44.21	22.50	1592.00	792.00	48.13	84.13	9.75	845
KET-RR-20048		48.00	221.0	112.5	44.21	22.50	2122.00	1056.00	60.13	108.13	9.75	1065
KET-RR-3006	300	6.00	354.6	190.0	70.93	38.00	425.56	228.00	19.13	25.13	12.25	441
KET-RR-30012		12.00	354.6	190.0	70.93	38.00	851.12	456.00	25.13	37.13	12.25	608
KET-RR-30018		18.00	354.6	190.0	70.93	38.00	1277.00	684.00	31.13	49.13	12.25	776
KET-RR-30024		24.00	354.6	190.0	70.93	38.00	1702.00	912.00	37.13	61.13	12.25	1034
KET-RR-30036		36.00	354.6	190.0	70.93	38.00	2553.00	1368.00	49.13	85.13	12.25	1385
KET-RR-30048		48.00	354.6	190.0	70.93	38.00	3405.00	1824.00	61.13	109.13	12.25	1720
KET-RR-4006	400	6.00	475.4	255.0	95.09	51.00	570.51	306.00	21.19	27.19	14.13	670
KET-RR-40012		12.00	475.4	255.0	95.09	51.00	1141.00	612.00	27.19	39.19	14.13	880
KET-RR-40018		18.00	475.4	255.0	95.09	51.00	1712.00	918.00	33.19	51.19	14.13	1000
KET-RR-40024		24.00	475.4	255.0	95.09	51.00	2282.00	1224.00	39.19	63.19	14.13	1317
KET-RR-40036		36.00	475.4	255.0	95.09	51.00	3423.00	1836.00	51.19	87.19	14.13	1746
KET-RR-40048		48.00	475.4	255.0	95.09	51.00	4564.00	2448.00	63.19	111.19	14.13	2162
KET-RR-5006	500	6.00	565.7	315.0	113.15	63.00	678.00	378.00	22.75	28.75	15.63	953
KET-RR-50012		12.00	565.7	315.0	113.15	63.00	1358.00	756.00	28.75	40.75	15.63	1300
KET-RR-50018		18.00	565.7	315.0	113.15	63.00	2037.00	1134.00	34.75	52.75	15.63	1500
KET-RR-50024		24.00	565.7	315.0	113.15	63.00	2716.00	1512.00	40.75	64.75	15.63	1800
KET-RR-50036		36.00	565.7	315.0	113.15	63.00	4074.00	2268.00	52.75	88.75	15.63	2210
KET-RR-50048		48.00	565.7	315.0	113.15	63.00	5431.00	3024.00	64.75	112.75	15.63	2700

Glad to know you are on market for hydraulic tools, and considering more about the quality goods, Like ENERPAC. Being named hydraulic tools manufacturing leader in China, and 20 years military factory experience in hydraulic area, KIET guarantee good quality and price for every hydraulic tools and equipments,

We have developed a strong market position with sales, service and repair of high force hydraulic equipment, along with the supply of spare parts to the hydraulic industry, while consistently providing a high standard of customer service.

We are a manufacturer in hydraulic tools, such as:

Hydraulic cylinders, jacks (5-1000ton), single acting and double acting, hollow plunger;

Hydraulic/ electric /pneumatic torque wrench (100-72000Nm);

Hydraulic bolt tensioner (100-11486NM); Hydraulic pullers (5-100 ton)

Hydraulic pumps, manual and electric type (max up to 3000bar);

Integrated hydraulic lifting system solutions ( 4-72 points lifting system for house translation or leveling, bridge supporting and tank welding supporting)

Hydraulic nut and couplings. (M50-Tr1000)

Our products have been widely used in industrial field such as steel plant, cement industry, chemical and refinery, bridge, railway construction and maintenance.
