Remote Control Double Acting Hydraulic Cylinder

Name: Remote Control Double Acting Hydraulic Cylinder
Brand: tool-buy.com
SKU: 798607795
Availability: InStock
Rating: 4.3 (67 reviews)

Price:	US $ 200-10000/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Money Gram

Contact Supplier

Jiangsu Canete Machinery Manufacturing Co., Ltd.

Showroom Product Company Profile

Prod Model:	KET-CLRG Series
Capacity:	50-1000 Ton
Stroke Range:	50-300mm
Closed Height:	166-815mm
Outside Diameter:	130-560mm
Plunger Diameter:	70-343mm
Color:	Yellow, Black, Orange, OEM
Working Pressure:	700bar
Product Name:	Remote Control Double Acting Hydraulic Cylinder
Weight:	17kg-1439kg
Warranty:	1 Year
Type:	Hydraulic Jack
Structure:	Hydraulic Jack
Power Source:	Hydraulic
Max Height:	>500mm
Capacity (',Load):	30-1000 Ton

Product Description

Hydraulic Oil Return Double Acting Hydraulic Jack

Product Description
Double-acting, for positive retractionIntegral
stop ring provides piston blow-out protection
Safety valve in retract side of cylinder helps to prevent damage in case of accidental over-pressurization
Plunger wiper reduces contamination, extending cylinder life
CR-400 coupler and dust cap included on all models
Baked enamel finish and plated pistons provide superior corrosion resistance

Product Picture

Our Services
One Year Warranty, repair and service for the whole life, question report response in 24 hours, and reply in 48 hours.

Company Information

Kiet is a professional manufacturing in hydraulic tools and products, we have been in the industry for more than 20 years. Since the establishment in 1995, we successfully transformed from OEM manufacturer to create our own brand Kiet, and our factory has been approved by CE, ISO9001: 2008 consecutively. Our products have been widely used in petrochemical, cement, shipbuilding, steel plant, and heavy constructions areas, etc.

Our main product category includes:
· Hydraulic cylinders and jacks
· Hydraulic bolting tools such as hydraulic torque wrench
· Hydraulic bolt tensioners, nut splitters.

FAQ
Q1: How can contact sales?
A1: Please call: 0086 18121376369 for pre-sales or click the contact find our website and email address.
Q2: How can I buy Kiet products in my country?
A2: Please send us an inquiry or email, we will reply to your if there is distributor in your country.
Q3: Can I have Kiet products catalog and price list?
A3: Please visit our English website: www.chinakiet.com/en to download our E-catalog, and send us an email for price list
Q4: How long does it take to get the product If I place an order?
A4: If products stock available, after confirmation of your payment or advance payment, we will pack and deliver in 3-7 days. If you select international parcel service, it can be arrived in 3-7 days. If it is by sea shipment, it will take 15-45 days depending on different locations.
Q5: How to make payment?
A5: First send us an inquiry, and we will reply you quotation, if our price suits you, we will prepare proforma invoice with our banking details.
Q6: Manufacturing time?
Q6: Please send us an inquiry for stock condition, if we don't have stock, and it is our standard products (refer to our model), it can be produced in 10-20 days. If it is customized, not our standard products, it will take 20-45 days to produce.
Why Choose Kiet?
Quality --- Kiet has been in the industry for than 20 years. We have been trusted by domestic mega stated-state owned companies, as well as international distributors and renowned brands. We put quality as lifeline. We never manufacture or sale defected product, or lowering our price at the cost of products quality.
Service --- Kiet promised to respond to customers products quality or service in 24 hours reported, and solutions shall be provided in 48 hours.

Model Number	Cylinder Capacity	Stroke	Maximum Cylinder Capacity (kN)		Cylinder Effective Area (cm2)		Oil Capacity (cm3)		Coll. Height (A)	Ext. Height (B)	Outside Dia. (D)	Weight
	ton	mm	Push	Pull	Push	Pull	Push	Pull	mm	mm	mm	kg
KET-CLRG-502	50	50	539	269	77,0	38,5	385	192	162	212	130	17
KET-CLRG-504		100	539	269	77,0	38,5	770	385	212	312	130	20
KET-CLRG-506		150	539	269	77,0	38,5	1155	577	262	412	130	23
KET-CLRG-508		200	539	269	77,0	38,5	1540	770	312	512	130	27
KET-CLRG-5010		250	539	269	77,0	38,5	1924	962	362	612	130	31
KET-CLRG-5012		300	539	269	77,0	38,5	2309	1155	412	712	130	34
KET-CLRG-1002	100	50	929	433	132,7	61,9	664	309	179	229	165	29
KET-CLRG-1004		100	929	433	132,7	61,9	1327	619	229	329	165	34
KET-CLRG-1006		150	929	433	132,7	61,9	1991	928	279	429	165	40
KET-CLRG-1008		200	929	433	132,7	61,9	2655	1237	329	529	165	46
KET-CLRG-10010		250	929	433	132,7	61,9	3318	1546	379	629	165	52
KET-CLRG-10012		300	929	433	132.7	61,9	3982	1856	429	729	165	58
KET-CLRG-1502	150	50	1390	675	198,6	96,5	993	482	196	246	205	39
KET-CLRG-1504		100	1390	675	198,6	96,5	1986	965	246	346	205	52
KET-CLRG-1506		150	1390	675	198,6	96,5	2978	1447	296	446	205	65
KET-CLRG-1508		200	1390	675	198,6	96,5	3971	1930	346	546	205	78
KET-CLRG-15010		250	1390	675	198,6	96,5	4964	2412	396	646	205	92
KET-CLRG-15012		300	1390	675	198,6	96,5	5957	2895	446	746	205	105
KET-CLRG-2002	200	50	1861	889	265,9	127,0	1330	635	212	262	235	55
KET-CLRG-2006		150	1861	889	265,9	127,0	3989	1905	312	462	235	91
KET-CLRG-20012		300	1861	889	265,9	127,0	7977	3809	462	762	235	146
KET-CLRG-2502	250	50	2565	1068	366,4	152,6	1832	763	235	285	275	89
KET-CLRG-2506		150	2565	1068	366,4	152,6	5497	2289	335	485	275	136
KET-CLRG-25012		300	2565	1068	366,4	152,6	10993	4578	485	785	275	207
KET-CLRG-3002	300	50	3193	1060	456,2	151,4	2281	757	322	372	310	184
KET-CLRG-3006		150	3193	1060	456,2	151,4	6843	2270	422	572	310	232
KET-CLRG-30012		300	3193	1060	456,2	151,4	13685	4541	572	872	310	303
KET-CLRG-4002	400	50	3919	1354	559,9	193,5	2800	967	374	424	350	270
KET-CLRG-4006		150	3919	1354	559,9	193,5	8399	2902	474	624	350	330
KET-CLRG-40012		300	3919	1354	559,9	193,5	16797	5804	624	924	350	421
KET-CLRG-5002	500	50	5114	1733	730,6	247,6	3653	1238	419	469	400	401
KET-CLRG-5006		150	5114	1733	730,6	247,6	10959	3713	519	669	400	480
KET-CLRG-50012		300	5114	1733	730,6	247,6	21918	7427	669	969	400	599
KET-CLRG-6002	600	50	5987	2068	855,3	295,4	4276	1477	429	479	430	474
KET-CLRG-6006		150	5987	2068	855,3	295,4	12829	4431	529	679	430	565
KET-CLRG-60012		300	5987	2068	855,3	295,4	25659	8862	679	979	430	701
KET-CLRG-8002	800	50	8234	2709	1176,3	387,0	5881	1935	484	534	505	741
KET-CLRG-8006		150	8234	2709	1176,3	387,0	17644	5806	584	734	505	868
KET-CLRG-80012		300	8234	2709	1176,3	387,0	35288	11611	734	1034	505	1058
KET-CLRG-10002	1000	50	10260	3792	1465,7	541,7	7329	2709	564	614	560	1062
KET-CLRG-10006		150	10260	3792	1465,7	541,7	21986	8126	664	814	560	1213
KET-CLRG-100012		300	10260	3792	1465,7	541,7	43972	16252	814	1114	560	1439

§ Models above 150 ton are also available with standard stroke lengths of 100, 200 and 250 mm.
