Prod Model: |
J21S-80 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brand: |
King Ball |
Warranty: |
2 Years |
Delivery Time: |
35 Days |
OEM: |
Ok |
Material: |
Steel |
Function: |
Punch Hole, Door Frame |
Type: |
General Punching Machine |
Controlling Mode: |
Artificial |
Automatic Grade: |
Semiautomatic |
Power Source: |
Hydraulic Pressure |
Precision: |
High Precision |
Product Description
Deep-throat power press with fixed bed
J23 series pressure machine is common type open can the pressure machine, its structure is simple, operation convenience, function credibility, the usage maintain convenience.J23 series shut type list orders the pressure machine fuselage of airplane straight line form design, well balanced to be subjected to dint, constant form, rigid and strong. Extremely high closing height, pack the mold space big, slippery piece six noodles direction, the accuracy is high, stability good. Outside support type especially the big machine do, exaltation the tool machine install stability, safety, inside place type, oil road ,electric circuit , beauty clean and neat, have a safety, dependable type more, the hands operation button the switch match pressure machine national security standard.
J23 series pressure machines is common type open type can the pressure machine,
1. Its structure is simple, operation convenience, function credibility, the usage maintain convenience.
2. J23 series shut type list orders the pressure machine fuselage of airplane srtaight line form design, well balanced to be subjected to dint, constant form, rigid and strong.
3. Extemely high closing height, pack the mould space big, slippery piece the piece six noodles directionn, the accurancy is high, stability good.
4. Outside support type especially the big machine do, exaltation the tool machine install stability, safety, inside place type, oil road, electric circuit, beauty clean and net, have a safety, dependable type more,
5. The hand operation button the switch match pressure machine national security standard.
This punch press machine can can punch hole, door frame and steel pipe.
Type | J23-80 |
Nominal Force (kn) | 800 |
Worktable Dimension (mm) | 480x750 |
Slider travel | 120 |
Distance from slider center to press body | 260 |
Travel times (min-1 ) | 50 |
Closing height (mm) | 380 |
Die hole size (mm) | Φ60x80 |
Worktable thickness (mm) | 90 |
Power (kw) | 7.5 |
Weight (kg) | 4500 |
Dimension LxWxH (mm) | 1750x1300x2600 |
