Kiet Special Electric Hydraulic Pump for Engineering Hydraulic Cylinder

Prod Model:	KET-DBZ
Name:	Electric Hydraulic Pump
OEM:	Yes
Color:	Customeized
Warranty:	1 Year
Working Pressure(MPa):	31.5
Flow(L/Min):	3-144
Oil Tank Capacity(L):	51-1594
Weight(Kg):	104-2048
Height(mm):	650-1200
Deliver Time:	7-15days
Structure:	Axial Plunger Pump
Cylinder Number:	Single Cylinder
Drive Mode:	Hydraulic Driven Reciprocating Pump
Pump Shaft Position:	Vertical
Type:	Radial
Power:	Electric

Product Description

Product Description
        Kiet Special Electric Hydraulic Pump for Engineering Hydraulic Cylinder

Special electric hydraulic pump for engineering hydraulic cylinder is pray coating, anti-corrosion, pollution-resistant, durable. Lightweight and compact design make it easy to be moved. Double speed pump design, with the high flow in low pressure. The actuator can be fast moved on no-load status- internal precise high and low pressure automatic reversing valve and external adjustable pressure valve to make it easy to calibrate the working pressure and avoid the over load. The motor starter has the function of preventing overload, overheat and leakage. The pump can be matched with both double acting and single acting cylinders. Choosing the solenoid valve electric hydraulic pump, remote operation can be realized.

Pictures




Technical Parameters

Model	Working	Flow	Motor	Motor	Oil Tank	Oil Tank Dimensions			Dimensions			Weight
	Pressure		Power	Speed	Capacity		(mm)			(mm)
	(MPa)	(L/min)	KW_	(r/min)	(L)	Length	Width	Height	Length	Width	Height	(kg)
KET-DBZ-300	31.5	3	3	1470	51	500	400	300	570	460	650	104
KET-DBZ-400	31.5	4	4	1470	51	500	400	300	570	460	660	106
KET-DBZ-550	31.5	5	5.5	1470	164	750	550	470	790	640	850	226
KET-DBZ-750	31.5	6	7.5	1480	164	750	550	470	790	640	890	236
KET-DBZ-1110	31.5	15	11	1480	191	800	600	470	840	700	950	294
KET-DBZ-2200	31.5	30	11x2	1480	433	1200	850	500	1240	950	980	596
KET-DBZ-1800	31.5	24	18.5	1480	291	1000	700	490	1040	830	1050	398
KET-DBZ-3700	31.5	48	18.5x2	1480	433	1200	850	500	1220	950	1060	684
KET-DBZ-5400	31.5	72	18.5x3	1480	850	2000	1000	500	2000	1130	1220	1214
KET-DBZ-7200	31.5	96	18.5x4	1480	1226	2500	1200	520	2500	1340	1190	1610
KET-DBZ-3000	31.5	36	30	1480	450	1200	850	520	1230	950	1220	622
KET-DBZ-6000	31.5	72	30x2	1480	850	1200	1000	500	2000	1130	1200	872
KET-DBZ-9000	31.5	108	30x3	1480	850	2000	1000	500	2000	950	1200	1496
KET-DBZ-12000	31.5	144	30x4	1480	1594	2500	1500	500	2530	1600	1200	2048

Our Service:
KIET provide one year guarantee for all the hydraulic tools. We promise if there is any dysfunction of the hydraulic tools during the quality warranty not by outside force, we will replace a new one for free. Any quality defects reported by customers will be responded in 24 hours.

Packaging & Shipping:
We provide Plywood packing for each pump, which can perfectly protect, the shipping can be by express parcel, by air or by sea shipping.

Company Information:
Jiangsu Canete Machinery Manufacturing Co., Ltd. Is a manufacturer engaged in design and manufacturing hydraulic cylinders (capacity covers from 10- 1000 tons), synchronous PLC hydraulic system, hydraulic pumps, hydraulic torque wrenches, and electric torque wrenches, and hydraulic components.
We successfully transformed from OEM manufacturer for Enerpac, Titan, to create our own brand KIET, and our factory has been approved by CE, ISO9001: 2008 consecutively.

Our customers includes many big Chinese industrial companies, such as China Petroleum, Baosteel, Sinopec, China State Grid, Jiangnan Shipyards, Sany Group, China Railway Construction Corporation. Our synchronous PLC hydraulic system had played a great role in the China high-speed railway constructions. In 2011, our sales revenue reached 30 million USD, making us one of the leaders in the Chinese hydraulic cylinders market especially in the extra-high hydraulic cylinders for industrial area and construction field.
We are a manufacturer in Hydraulic tools, such as:
Hydraulic cylinders, jacks (5-1000ton), single acting and double acting, hollow plunger;
Hydraulic/ electric /pneumatic torque wrench (100-72000Nm);
Hydraulic bolt tensioner (100-11486NM); Hydraulic pullers (5-100 ton)
Hydraulic pumps, manual and electric type (max up to 3000bar);
Integrated hydraulic lifting system solutions ( 4-72 points lifting system for house translation or leveling, bridge supporting and tank welding supporting)
Hydraulic nut and couplings. (M50-Tr1000)
Our products have been widely used in industrial field such as steel plant, cement industry, chemical and refinery, bridge, railway construction and maintenance.
