| Prod Model: |
HZ744 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Segment Material: |
Diamond Powder |
| Segment Type & Shape: |
Normal, Turbo; Sandwich,Groove,etc |
| Base & Matrix Type: |
Normal, Silent |
| Slot Type: |
V Shape, U Shape(Narrow or Wide),Key Hole Shape |
| Manufacturing Art: |
Welding |
| Usage & Application: |
Cutting Granite, Marble, Sandstone,Concrete |
| Cutting Direction: |
Vertical Cut, Horizontal Cut |
| Cutting Condition: |
Dry Cut, Wet Cut |
| Perfromance Comparison: |
Sharp Diamond Blade, Wearable Diamond Blade |
| Quality Grade: |
High, Medium, Normal |
| Shape: |
Rectangle |
Product Description
Product discription:
1. For Single Blade and Multi-disc blade used to cut and split stone slab, block and cubes
2. For smooth cutting,with a perfect chip-free edge
3. Best quality control system & select materials
4. Specially developed for general purpose cutting of hard,medium hard, soft granite
Specification:
| Diameter | Segment Dimension |
| Length | Thickness | Height |
| | T1 | T2 | |
| 250mm | 40 | 1.8/2.0 | 8/10 |
| 300mm | 40 | 1.8/2.2/2.4 | 8/10/12 |
| 350 mm | 40 | 3.2/3.6 | 8/10/12 |
| 400 mm | 40 | 3.2/3.6 | 8/10/12 |
| 500 mm | 40 | 4.0 | 10/12/15 |
| 600 mm | 40 | 4.6 | 10/12/15 |
| 800 mm | 40 | 5.6 | 10/12/15 |
| 1200 mm | 24 | 8.2
7.5 | 7.6
6.5 | 13.5/15
12/13 |
| 1600 mm | 24 | 9.0 | 8.4 | 13.5/15/20 |
| 1800 mm | 24 | 8.8 | 9.4 | 13.5/15/20 |
| 2000 mm | 24 | 10 | 11 | 15/20 |
| 2200 mm | 24 | 10 | 11 | 15/20 |
| 3000 mm | 24/30 | 12 | 13 | 20 |
| 3500 mm | 24/30 | 12 | 13 | 20 |
Other Specification Is Availbale Upon Your request.
