Outdoor DIP Full Color P16.67 Advertising LED Display
| Price: |
US $ 660-720/Square Meter |
| Min Order: |
1/Square Meter |
| Pay Type: |
L/C,T/T,Western Union |
| Prod Model: |
P16.67 outdoor fixed DIP |
| LED Type: |
DIP349 |
| Module Size: |
200*400mm |
| Cabinet Material: |
Aluminum Cabinet |
| Cabinet Weight: |
30kg |
| Brightness: |
6500nits |
| Refresh Rate: |
>3840Hz |
| Warranty: |
2 Years |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP67 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
300W / m² |
| Scanning Mode: |
Static Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
ETL |
| Pixel Pitch: |
16.67mm |
| Pixel Density: |
3600 Dots/Sqm |
Product Description
Outdoor DIP Full Color P16.667 Advertising LED DisplayLED Display Products Detail:
Specifiction:| Item | K7110 | K7116 |
| Pixel pitch | 10.0 mm | 16.67mm |
| Module size(W*H) | 200*400mm | 200*400mm |
| Cabinet size(W*H*T) | 800*800*100 mm | 800*800*100 mm |
| Cabinet resolution | 80*80 Dots | 48*48 Dots |
| Cabinet material | Aluminum cabinet | Aluminum cabinet |
| Cabinet weight | 32 Kg | 30 Kg |
| Gray scale | 16384 | 16384 |
| Refresh rate | 1920 Hz | 1920 Hz |
| White balance brightness | 6000 Nit | 6500 Nit |
| Horizontal viewing angle | 120 Degree | 120 Degree |
| Vertical viewing angle | 65 Degree | 65 Degree |
| Power | 650 W/M2 | 650 W/M2 |
| IP level | IP65/43 | IP65/43 |
| Application scene | Outdoor |
| Work environment | -20…65ºC RH 10%…90% |
| Optical character | Pixel configuration | DIP349 1R1G1B | DIP349 1R1G1B |
| Min viewing distance | 10.0 M | 16.0 M |
| Best viewing distance | 10.0-100 M | 15.0-200 M |
| Pixel density | 10,000 Dots/m2 | 3600 Dots/m2 |
| Highest brightness | 6500 Nit | 7000 Nit |
| Module character | Module voltage | 4.6-5.2V | 4.6-5.2V |
| Module current(MAX) | 5.5A | 5.2A |
| Scan mode | 1/4S constant current | Static constant current |
| Circuit scheme | High refresh rate, no ghost. | High refresh rate, no ghost. |
| MTBF | ≥10000 Hours | ≥10000 Hours |
| Lifespan | ≥100000 Hours | ≥100000 Hours |
| Pixel failure ratio | <3/100000 | <3/100000sqm |
Our service 1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
6. Keasy can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.
Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, China
5. Warranty time: 2years
6. Delivery time: 15 working daysContact Us:Contacts: Lotus Wong
Phone: +86-755-61805158
Fax: +86-755-66855528
Mobile: +86-13113695434
Web site: www.keasyled.com
Shenzhen Keasy Technology co, . Ltd is professional company, delicated to providing LED display products application solution and service. Shenzhen Keasy Technology Co., Ltd is engaged in Designing & selling indoor and outdoor advertising LED display, indoor and outdoor rental LED display, transparent see thru LED screen, and customized LED display solution.
We are a professional LED display industry specialist team, devote to LED display screens solution and services for indoor&outdoor Advertising, Sports, entertainment and security industry, including requirement analysis, system solution design, products R&D and customization. Since its has been established, we have gathered the advantages resource of n R&D, pre-sale and selling, after-sales service, to cut the intermediate links, directly to customers face to face, and focus on customer needs. We are delicated to develop segment market of LED display applications, create value to customers, and share value with customers more than products.
