| Prod Model: |
P10 |
| Module Size: |
320*160 |
| LED: |
SMD3535 |
| Refresh Rate: |
1920Hz |
| Maintenance: |
Back/Front |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP54 |
| Pixel Pitch: |
10mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Market Display |
| Average Power Consumption: |
220W / m² |
| Pixel Density: |
10000 dot / m² |
| Scanning Mode: |
1/2 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
ETL |
Product Description
P10 outdor Fixed installation Advertising LED displaySMD P10 Outdoor LED Display ( 320x160mm)1. Brightness: ≥6000cd/m2
2. Average power consumption: ≤350 W/m2
3. Manufacturer: over 10 years
4. Quick response: replying inquiry within 12hrs
5. On time delivery + patient after-sales service
6. Quality guarantee: CE, RoHS, FCC, IP65, ISO9001 + 100% testing before shipping.Specification: | The specifications of modules |
|
| Items | LED Display Parameter |
| Product Model | P10 SMD Full Color Led Display Module |
| Module size | 320mm*160mm |
| Pixel pitch | 10mm |
| Pixel density | 10000dots/m2 |
| Pixel configuration | 1R1G1B |
| Module resolution | 32*16dots |
| Module maximum power consumption | 20W |
| Module Thickness | 25CM |
| Module Weight | 0.45kg |
| Scanning method | 1/4 |
| Interface | HUB75 |
| Brightness | 7000cd/m2 |
| The specifications of cabinets |
|
| Cabinet size | 960mm*960mm |
| Module quantity | 3*6 |
| Power supply | 5V/40A 5V/60A |
| Cabinet resolution | 96*96dots |
| Optimal viewing distance | 10M~150M |
| Optimal viewing angle | 160°(W) 120°(H) |
| RHWorking temperature | (Work :-20°C~+50°C) |
| System operating humility | 10%-95% |
| The specifications of power supplier |
|
| Operating Voltage | AC220V±10% |
| Average power consumption | 350W/m2 |
| Maximum power consumption | ≤800W/m2 |
| Electric current | ≤20mA(single LED) |
| The specifications of control card |
| Control system | Nova/Linsn |
| Operating system | WIN98/2000/NT/XP |
| Control model | Synchronization with PC |
| The specifications of the main technical parameters |
|
| Driving device | Constant Current Driving |
| Refresh rate | ≥1920HZ |
| Grey scale | RGB Each 256, can display 16.7M colors) |
| MTBF | ≥10,000hours |
| Power switch | Automatic Switch |
| Display Mode | 960*960/1280*960/960*800 |
Our service 1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
6. Keasy can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.
Trade Terms 1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, China
5. Warranty time: 2years
6. Delivery time: 15 working days
