| Price: | US $ 400-800/Square Meter |
|---|---|
| Min Order: | 1/Square Meter |
| Pay Type: | T/T,Western Union |
| Prod Model: | P6 outdoor LED display |
|---|---|
| Product Name: | Outdoor High Brightness P6/P8/P10 LED Display Scre |
| LED Lamp: | Nation Star / Epistar /Kinglight |
| IC: | Mbi5124 IC |
| Controller: | Nova Star /Linsn /Colorlight |
| Warranty: | 2-5 Years |
| IP Grade: | IP 65 |
| Cabinet Size: | 960*960mm / 768*768mm /1024*1024mm |
| Use Voltage: | AC 110-240V |
| Weight: | 35-45 Kg /M2 |
| Maximum Power Consumption: | 1000W/M2 |
| Tube Chip Color: | Full Color |
| Display Function: | Market Display |
| Scanning Mode: | 1/8 Scan |
| Display Type: | LED Video Display |
| Application: | Advertising |
| Certification: | FCC |
| Average Power Consumption: | 600W/M2 |
| Pixel Pitch: | 6mm |
| IP Rating: | IP65/IP54 |
| Pixel Density: | 27777DOT/M2 |
| Pixel Configuration: | SMD2727 |
| Outdoor High Brightness P6/P8/P10 LED Display Screen | ||
| NO | HD small pixel LED display | P1.5625 / P1.667/ P1.923/ P2 |
| 1 | Hot rental LED display | P3 /P3.91 /P4 /P4.81 /P5.95 /P6 / P6.25/P6.67 |
| 2 | Outdoor fixed LED display | P4/P5 /P6 /P8 /P10 /P16 /P20 |
| 3 | LED Control System | Nova Star / LINSN /Colorlight /Listen |
| 4 | LED | Nation Star /Epistar /Kinglight |
| 5 | IC | MBI5124 /5153 IC |
| 6 | Power supply | Meanwell / G-energy |
| 7 | Cabinet kind | Iron /Aluminum /Die-casting /Fiber Aluminum |
| NO | Parameter | |
| 1 | Pixel Pitch | 6/8/10 mm |
| 2 | Cabinet Size | 960*960mm / 768*768mm /1024*1024mm |
| 3 | Pixel density | 27,777 dots/m2 /15,625dots/m2 / 10,000 dots/m2 |
| 4 | Color temperature | 6000K--8000K |
| 5 | Viewing angle | H:140;V:140 |
| 6 | Brightness | 5500-7500 cd/m2 ,brightness automatically adjusted |
| 7 | Gray level | 256 RGB each ,display 16.7M colors ,vivid and perfect video effect |
| 8 | Dead LED lamp rate | ≤0.1‰ |
| 9 | Non-Flatness | <0.2mm |
| 10 | Module interval | <0.2mm |
| 11 | Packaging Gross Weight(KG) | 45 kg (Estimated data) |
| 12 | Packaging dimension | 1m*1m*1.15 m (6cabinet in one case) |
| 13 | Maximal power/m2 | P6 /P8 :1000 W/m2 P10 : 800 W/m2 |
| 14 | Brightness adjusted | 256 grade by auto-optic/color &8 grade by hand |
| 15 | Input signal | RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc |
| 16 | Life-span | ≥1 00,000 hours |
| 17 | MTBF | 5,000 hours |
| 18 | Frame frequency | 25 - 60 Hz / s |
| 19 | Refresh rate | ≥2,000 Hz ,if you want ≥ 3840 Hz we can design special offer for you |
| 20 | Signal Input(with video processor) | HDMI, DVI, VGA, RF, S-Video, RGB, RGBHV, YUV, YC&Composition, etc. |
| 19 | Control Distance | 120 m (no repeating); Optical fiber transmission: 0.5km- 10km |
| 20 | Systems Operating Platform | Windows XP, Win 7, Win8, Win8.1, Win10 |
| 1).Leader Team | CEO with 8 years led display industry experience, keen market observation ability |
| 2).Engineer Team | +Chief Engineer Director with 8 years professional technical experience +3 Engineers speaking English fluently fly all the world |
| 3).Production Team | 72 Hours Display Testing Time + 24 Hours Module Testing Time + Serious QC Process |
| 4).Sales Team | + 5 years Excellent Domestic Big Government LED Designer + 3 years Expanding International Trade Experience . + All Sales Can Respond your Inquiry within 12 hours |
| 1).Price :We can give you the most satisfying price ,because we signed long time VIP Cooperation Contract with raw material suppliers since we step into led industry .Once the market change ,we will flexibly adjust the price and timely notify everyone of you about our update price. YOU WANT = WE DO .First time trial order will let you strongly shake hands with us . We warmly welcome any kind quality inspection process from your team . 2).Quality : We seriously practice 24 hours led module testing time and 72 hours led display aging time .Before shipping and within the warranty time ,our team will track the goods situation to satisfy all your request . 3).Production : Support Any Kind Special Customized Design . YOU NEED =WE DESIGN .We design exactly the same material you mentioned with our team in the sales contract and business negotiation process . We are direct factory ,if your led project time is definitely fixed , with no any change , We will arrange your order firstly to catch up with your time . MEET YOUR TIME = SUPPORT OUR TEAM . |
| Q1:Are you a factory or just a trade company? A1:Our HONGHUI is a led display factory with R&D department and production line,professional engineering team and energetic sales team.Warmly welcome to visit our HONGHUI factory and have face-to-face business talk to better understand each other .Or when you are free ,we can have SKYPE VIDEO TALKING ,and show our HONGHUI factory. Q2:Can you tell me why I should choose your company ? A2:Concentration makes professional .Professional achieves successful . Our HONGHUI have 8 years professional led technical experience .We are 5 years gold supplier for China government led project .Now ,we are largely expanding our international market.From 2009 to 2017, we only do LED .Now and In the future, we still do LED.We can cooperate from trail order to establish trust step by step . Q3: What's the warranty of your LED Display ? A3: 2-5 years warranty .and 96360hours life span.During the warranty period ,we can offer you related after-sales service. Our professional engineering team are ready for your question during 6:00-23:30. Q4: What's your payment term? How long is your delivery time ? A4: We accept T/T ,ALIBABA Trade Assurance ,Paypal ,Western Union ,Money Gram, and Cash .At least 30-50 % deposit in advance, and the balance should be paid before delivery.Our average Production time is 7-15 working days after receiving the deposit.If your order is rapidly urgent ,we can arrange your order firstly. Q5:How can I get technical support? Q5: We treasure every customer that shake hands with our HONGHUI . We offer you TEAMVIEWER help by Online Video and can send professional engineer to your city to offer on-site guide . Q6: What about your service? A6: We have a professional 8 years technical team answering your question during 6:00-23:30. We have an energetic and patient sales team .We can offer a complete LED design solution for your LED project before confirming the order . We can instruct you how to use, configure your led display , and do some maintenance with spare parts. Also, we can send professional engineer to your city to offer on-site guide and offer training.Mostly,our led display do not have big problems within warranty time. Q7: Is Available to print customer required logo on your led product ? A7: Surely it is .Please inform and confirm the logo design details with our team ahead of the production . Then ,we will follow your requirements . |
