| Prod Model: |
SMV8 |
| Gross Cut Capacity: |
200mm |
| Width Of Cut: |
1250mm |
| Saw Blade: |
300mm |
| Type: |
Table Panel Saw |
| Layout: |
Horizontal |
| Controlling Mode: |
Artificial |
| Automatic Grade: |
Semiautomatic |
| Precision: |
Precision |
| Certification: |
CE |
Product Description
| 01) Dimensions sliding table:3200×370mm |
| 02) Gross cut capacity:3200mm |
| 03) Width of cut between saw blade and rip fence:1250mm |
| 04) Saw blade φ:300mm(φ250-φ350) |
| 05) Height of cut φ300mm:90mm |
| 06) Diameter of guide shaft spindle :50mm |
| 07) Height of cut with saw blade φ300mm at 45°:60mm |
| 08) Speed of main saw blade:3000/4000/6000rpm |
| 09) Spindle diameter:30mm |
| 10) Tilling saw blade:0-45° |
| 11) Main motor:5.5kw |
| 12) Scoring saw blade:120mm |
| 13) Speed of scoring saw blade:9000r/min |
| 14) Spindle of scoring saw:22mm |
| 15) Motor:0.75kw |
| 16) Net weight:760kg |
| 17) Gross weight (wooden packing case):870kg |
| 18) Overall dimensions:3250×3150×900mm |
01) Dimensions sliding table:3200×370mm
02) Gross cut capacity:3200mm
03) Width of cut between saw blade and rip fence:1250mm
04) Saw blade φ:300mm(φ250-φ350)
05) Height of cut φ300mm:90mm
06) Diameter of guide shaft spindle :50mm
07) Height of cut with saw blade φ300mm at 45°:60mm
08) Speed of main saw blade:3000/4000/6000rpm
09) Spindle diameter:30mm
10) Tilling saw blade:0-45°
11) Main motor:5.5kw
12) Scoring saw blade:120mm
13) Speed of scoring saw blade:9000r/min
14) Spindle of scoring saw:22mm
15) Motor:0.75kw
16) Net weight:760kg
17) Gross weight (wooden packing case):870kg
18) Overall dimensions:3250×3150×900mm
Main Features and Standard fitting:
01) 50mm diameter Guide shaft spindle
02) Full size extentioin tables in right side and rear side
03) Lubricatioin pump
04) Support feeding frame
05) 2nd generation front control panel hood
06) Type-A protection hood
07) Advanced LED readout
08) Hold down clamp
09) Manual tilting 45 degree
10) Max saw blade capacity 350mm
11) Double scoring saw blade
