Prod Model: |
SMV8D-X |
Gross Cut Capacity: |
200mm |
Width Of Cut: |
1250mm |
Saw Blade: |
300mm |
Type: |
Table Panel Saw |
Layout: |
Horizontal |
Controlling Mode: |
Artificial |
Automatic Grade: |
Semiautomatic |
Precision: |
Precision |
Certification: |
CE |
Product Description
01) Dimensions sliding table:3200×435mm |
02) Gross cut capacity:3200mm |
03) Width of cut between saw blade and rip fence:1300mm |
04) Saw blade φ:300mm(φ250-φ400) |
05) Height of cut φ400mm:80mm |
06) Height of cut with saw blade φ300mm at 45degree:55mm |
07) Speed of main saw blade:3000/4000/5000rpm |
08) Spindle diameter:30mm |
09) Tilling saw blade:0-45° |
10) Main motor:5.5KW |
11) Scoring saw blade:120mm |
12) Speed of scoring saw blade:8000r/min |
13) Spindle of scoring saw:20mm |
14) Motor:0.75kw |
15) Net weight:1080kg |
16) Overall dimensions:3350x3600x900mm |
01) Dimensions sliding table:3200×435mm
02) Gross cut capacity:3200mm
03) Width of cut between saw blade and rip fence:1300mm
04) Saw blade φ:300mm(φ250-φ400)
05) Height of cut φ400mm:80mm
06) Height of cut with saw blade φ300mm at 45degree:55mm
07) Speed of main saw blade:3000/4000/5000rpm
08) Spindle diameter:30mm
09) Tilling saw blade:0-45°
10) Main motor:5.5KW
11) Scoring saw blade:120mm
12) Speed of scoring saw blade:8000r/min
13) Spindle of scoring saw:20mm
14) Motor:0.75kw
15) Net weight:1080kg
16) Overall dimensions:3350x3600x900mm
Main Features and Standard fitting:
01) Both main saw and scoring saw blades are electric lifting and tilting
02) Servo drive rip fence
03) Max main saw blade size 400mm
04) Double blades for scoring saw
