Polycrystalline Diamond Compact Bit PDC/PDC Cutter/Oil Synthetic Diamond PDC Bit

Polycrystalline Diamond Compact Bit PDC/PDC Cutter/Oil Synthetic Diamond PDC Bit
Price: US $ 10/Piece
Trade Terms: CIF,EXW
Min Order: 10/Piece
Pay Type: T/T,Western Union,Paypal
Prod Model: HX 803
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name: PDC for Oil Drilling Industry
Certification: ISO9001
Factory: Hongxiang
History: 26 Years
Address: Shangqiu ,China
Type: Cutter
Material: Polycrystalline Diamond
Work Type: Cut Off

Product Description

Introduction
PDC bits uses PDC as main cutting components, with the excellent wear-ability and impact toughness of the PDC.
It has a long useful life, high-efficiency, and good cost performance.
PDC bit is mainly used for drilling soft and big drainage.

PDC model:
803/908/1308/1313/1608/1613/1616/1908/1913/1916/1919

PDC application:
1. For oil drilling
2. For coal drilling
3. For hard material drilling



All of our business is carried out in full compliance with the ISO9001 Certification.
Please contact us if you would like any further information.
Product NumberDiameter
(D)(mm)
Height
(T) (mm)
Diamond Thickness
(t) (mm)
Diamond
Chamfer
(mm)
130813.44±0.038.00±0.102.30±0.200.30±0.10
131313.44±0.0313.20±0.102.30±0.200.30±0.10
160815.88/16.00±0.038.00±0.102.30±0.200.30±0.10
161315.88/16.00±0.0313.20±0.102.30±0.200.30±0.10
190819.05±0.058.00±0.102.30±0.200.30±0.10
191319.05±0.0513.20±0.102.30±0.200.30±0.10
191619.05±0.0516.31±0.102.30±0.200.30±0.10


Factory introduction :

Zhecheng Hongxiang Superhard Material CO.,LTD was founded in 1990 which in affiliated with Wanke Group. The company is a high-tech enterprise with modern management experience and strong research and development ability. Besides, it has won many national and local awards and obtained several invention patents.

Constant innovation and good faith are our foothold.

 Our products has exported to United Kingdom France , Germany, Spain, Italy, USA, Canada, Brazil, Japan, Korea, Thailand, Vietnam, India, Egypt, Iran, Turkey etc 52 countries and participated in many

 Domestic and international exhibitions. Besides, our product has won good satisfaction and recognition by domestic and foreign customers.
Zhecheng Hongxiang Superhard Material Co., Ltd. Affiliated with Wanke Group, is a highly professional and experienced manufacturer of synthetic diamond powder & diamond tools in China. We have specialized in this field over 27 Years and always dedicated to the produce the diamond tools in high quality and good service.

Our products include,

Synthetic diamond

Diamond powder

Diamond saw blade

Diamond drill bit

Poly crystalline Diamond composite ( PDC )

PCD wire drawing dies

Diamond glass tools

Diamond polishing pad

Diamond cutting tools

Diamond grinding tools

Diamond wheels

Diamond tools, etc.

Why choose us?

1. Since 1990, with over 27 years diamond tools manufacturer experience.

2. Rich experience in OEM order

3. Advanced production equipment

4. Own design team, can help you custom the packaging

5. Own provincial engineering technology center

6. D&B and ISO9001 Certificates

We are a professional synthetic diamond powder & diamond tools company integrating development, production and sales. Factory located in middle of China-Henan, with more than 124000 square meters. "High quality products, competitive prices, and classic services" is the soul of our business.

Warmly welcome all partners to join us for mutual benefits cooperation.
