Polycrystalline PDC Cutter for Oil & Coal Drilling Bit

Name: Polycrystalline PDC Cutter for Oil & Coal Drilling Bit
Brand: tool-buy.com
SKU: 685002742
Availability: InStock
Rating: 5 (29 reviews)

Price:	US $ 1.3/Piece
Trade Terms:	EXW,CIF,CIP
Min Order:	2/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Zhecheng Hongxiang Superhard Material Co., Ltd.

Showroom Product Company Profile

Prod Model:	HX PDC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	Any Size
Certificate:	ISO9001
Factory Address:	Shangqiu, China
Factory History:	26 Years
Factory Brand:	Hongxiang

Product Description

1. High hardness and wearability
2. Sorts of shapes and sizes
3. High toughness

Note:
1. Mount at temperatures not exceeding 650 degree.
2. Maximum recommended bearing diameter for "soft"nonferrous wire.
"hard"wire diameter normally should noe exceed 65% of this diameter.
ABOUT US:
Henan Wanke Diamond Tools Co., ltd is affiliated with Wanke Group. The company is a high-tech enterprise of diamond covers an area more than 124000m2, inclouding five standard workshops, one office buliding and one research building. It is also a procincial engineering technology center.

The main products are polycrystalline diamond composite(PDC), diamond saw blade, diamond glass tools, diamond wheel and diamond powder.

Product Number	Diameter (D)(mm)	Height (T) (mm)	Diamond Thickness (t) (mm)	Diamond Chamfer (mm)
1308	13.44±0.03	8.00±0.10	2.30±0.20	0.30±0.10
1313	13.44±0.03	13.20±0.10	2.30±0.20	0.30±0.10
1608	15.88/16.00±0.03	8.00±0.10	2.30±0.20	0.30±0.10
1613	15.88/16.00±0.03	13.20±0.10	2.30±0.20	0.30±0.10
1908	19.05±0.05	8.00±0.10	2.30±0.20	0.30±0.10
1913	19.05±0.05	13.20±0.10	2.30±0.20	0.30±0.10
1916	19.05±0.05	16.31±0.10	2.30±0.20	0.30±0.10

Key words	PDC cutter , Polycrystalline diamond compact cutter , Oil drilling bit part PDC
Diameter	6mm - 20mm
Thickenss	3mm - 20mm
Diamond Thickness	2.5mm , 1.0mm , 1.5mm , 2.0mm , 2.3mm
Application	For oil drilling bit ; For coal drilling bit ; For stone cutting ; For mining drilling bit ;
Standard Tolerance	0.001mm
Bond	Cobalt based
Grit	1um - 3um - 5um - 10um - 25um - 50um
Temperature resistant	650 degree
Quality Guarantee	Quality problem , we will exchange new one for you .
Note	1.Mount at temperautres not exceeding 650 degree . 2.Maximu recommend bearing diameter for "soft" nonferrous wire . " Hard " wire diameter normally should not exceed 65% of this diameter .
Packing	plastic bag & carton ; plastic box .
Shipping ways	TNT ,DHL,FEDEX,EMS,UPS ,AIR SHIPPING ,SEA SHIPPING
Shipping time	5-7 work days
Payment terms	100% prepayment by T/T , western union , Paypal , Credit
Contact Person	Ms.Belinda
Factoty	ZHECHENG HONGXIANG
Website	www.hnhongxiang.com
Factory address	Shangqiu city , Henan province , China
Factory history	26 years
Factory main products	1. PCD die blanks & PCD die 2. PDC cutter for oil drilling bit 3. PCD cutting tools 4. Diamond powder

Zhecheng Hongxiang Superhard Material Co., Ltd. Affiliated with Wanke Group, is a highly professional and experienced manufacturer of synthetic diamond powder & diamond tools in China. We have specialized in this field over 27 Years and always dedicated to the produce the diamond tools in high quality and good service.

Our products include,

Synthetic diamond

Diamond powder

Diamond saw blade

Diamond drill bit

Poly crystalline Diamond composite ( PDC )

PCD wire drawing dies

Diamond glass tools

Diamond polishing pad

Diamond cutting tools

Diamond grinding tools

Diamond wheels

Diamond tools, etc.

Why choose us?

1. Since 1990, with over 27 years diamond tools manufacturer experience.

2. Rich experience in OEM order

3. Advanced production equipment

4. Own design team, can help you custom the packaging

5. Own provincial engineering technology center

6. D&B and ISO9001 Certificates

We are a professional synthetic diamond powder & diamond tools company integrating development, production and sales. Factory located in middle of China-Henan, with more than 124000 square meters. "High quality products, competitive prices, and classic services" is the soul of our business.

Warmly welcome all partners to join us for mutual benefits cooperation.
