| Price: | US $ 60-65/Square Meter |
|---|---|
| Min Order: | 100/Square Meter |
| Pay Type: | L/C,T/T |
| Prod Model: | BYPM-90 |
|---|---|
| Hole Size: | 0.2mm-300mm |
| Thickness: | 0.05mm-10mm |
| Sheet Size: | 1mx2m, 4feetx8feet, 4feetx10feet or up |
| Shape: | Panels or Limited Specifications for Coils |
| Finishing: | Anodizing |
| Description | Hole Size(mm) | Pitch(mm) | Open Area | Thickness(mm) | Description | Hole Size(mm) | Pitch(mm) | Open Area | Thickness(mm) |
| R0.8 T2 | 0.80 | 2.00 | 15% | 0.4 0.5 0.8 1.0 1.2 1.5 2.0 2.5 3.0 4.0 5.0 6.0 | R5 T10 | 5.00 | 10.00 | 23% | 0.4 0.5 0.8 1.0 1.2 1.5 2.0 2.5 3.0 4.0 5.0 6.0 |
| R1 T2 | 1.00 | 2.00 | 23% | R5 T25 | 5.00 | 25.00 | 4% | ||
| R1.2 T2.25 | 1.20 | 2.25 | 26% | R6 T8.5 | 6.00 | 8.50 | 45% | ||
| R1.2 T2.5 | 1.20 | 2.50 | 21% | R6 T9 | 6.00 | 9.00 | 40% | ||
| R1.5 T2.75 | 1.50 | 2.75 | 27% | R6 T10 | 6.00 | 10.00 | 33% | ||
| R1.5 T3 | 1.50 | 3.00 | 23% | R7 T10 | 7.00 | 10.00 | 44% | ||
| R1.8 T3.5 | 1.80 | 3.50 | 24% | R8 T11 | 8.00 | 11.00 | 48% | ||
| R2 T3 | 2.00 | 3.00 | 40% | R8 T12 | 8.00 | 12.00 | 40% | ||
| R2 T3.5 | 2.00 | 3.50 | 30% | R8 T15 | 8.00 | 15.00 | 26% | ||
| R2 T4 | 2.00 | 4.00 | 23% | R10 T13 | 10.00 | 13.00 | 54% | ||
| R2.5 T3.5 | 2.50 | 3.50 | 46% | R10 T14 | 10.00 | 14.00 | 46% | ||
| R2.5 T4 | 2.50 | 4.00 | 35% | R10 T15 | 10.00 | 15.00 | 40% | ||
| R2.5 T4.5 | 2.50 | 4.50 | 28% | R10 T18 | 10.00 | 18.00 | 28% | ||
| R2.5 T5 | 2.50 | 5.00 | 23% | R12 T16 | 12.00 | 16.00 | 51% | ||
| R3 T5 | 3.00 | 5.00 | 33% | R12 T17 | 12.00 | 17.00 | 45% | ||
| R3 T6 | 3.00 | 6.00 | 23% | R15 T20 | 15.00 | 20.00 | 51% | ||
| R3.5 T5 | 3.50 | 5.00 | 44% | R15 T21 | 15.00 | 21.00 | 46% | ||
| R4 T5 | 4.00 | 5.00 | 58% | R20 T25 | 20.00 | 25.00 | 58% | ||
| R4 T6 | 4.00 | 6.00 | 40% | R20 T27 | 20.00 | 27.00 | 50% | ||
| R4 T8 | 4.00 | 8.00 | 23% | R20 T28 | 20.00 | 28.00 | 46% | ||
| R5 T7 | 5.00 | 7.00 | 46% | R20 T30 | 20.00 | 30.00 | 40% | ||
| R5 T8 | 5.00 | 8.00 | 35% | R25 T34 | 25.00 | 34.00 | 49% |
| Contact | Bruce Wang |
| Skpe | bingyebruce |
| 008618230486330 | |
| Web: | www.bingyewiremesh.com |
