| Price: | US $ 0.5-30/Meter |
|---|---|
| Min Order: | 1/Meter |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | rubber hose |
|---|---|
| Temperature Range: | -40°c / +100°c |
| Inner Tube: | Oil Resistant Synthetic Rubber |
| Reinforcement: | Two Braids of High Tensile Steel Wire |
| Cover: | Environment Resistant Synthetic Rubber |
| Standards: | En853 2sn-SAE 100r2at-ISO 1436-1 2sn |
| Application: | Medium-High Pressure Lines |
| Capability: | Rubber Oil Hose |
| Color: | Black |
| Material: | Synthetic Rubber |
Structure
1.Inner tube: Nitrile
2.Reinforcement: Two layers of Braided high-tensile steel wire
3.Cover: black neoprene blend,meets MT98 and GB/T 15907 Flame resistance
4.Temperature range: -40 to 212°F (-40 to 100°C)
5.Application standards: EN853 2SN, GB3683.1 2SN, SAE J517 R1S, ISO 1436 2SN
Application
1.hydraulic hose with fittings is a kind of high pressure hose for high-pressure liquid transmission by hydraulic transmission and industrial and agricultural machinery, etc.
2.It is suitable for transporting hydraulic fluids like ethanol, hydraulic liquid, fuel oil, lubricating oil and emulsions, etc.
Working Temperature
Oil: -40°C to +100°C, Air: -30°C to 50°C, Water Emulsion under +80°C
Features
1.The hydraulic hose with fittings is in a variety of specifications and has accurate calibers;
2.It is excellent in oil resistance and has long life in impulse resistance.
3.It can be equipped with metal joints and combined into assemblies of various types.
General Technical Data for 2SN Hydraulic Hose
| I.D | R.O.D. | C.T | O.D | MAX W.P. | MIN B.P. | MIN B.R. | WEIGHT | |||||||
| mm | inch | Min | Max | Min | Max | Min | Max | Max | bar | psi | bar | psi | mm | kg/m |
| mm | mm | mm | mm | mm | mm | mm | ||||||||
| 5 | 3/16" | 4.6 | 5.4 | 10.6 | 11.6 | 0.8 | 1.5 | 14.1 | 415 | 6020 | 1650 | 24076 | 90 | 0.27 |
| 6 | 1/4" | 6.2 | 7.0 | 12.1 | 13.3 | 0.8 | 1.5 | 15.7 | 400 | 5800 | 1600 | 23204 | 100 | 0.34 |
| 8 | 5/16" | 7.7 | 8.5 | 13.7 | 14.9 | 0.8 | 1.5 | 17.3 | 350 | 5080 | 1400 | 20304 | 115 | 0.39 |
| 10 | 3/8" | 9.3 | 10.1 | 16.1 | 17.3 | 0.8 | 1.5 | 19.7 | 330 | 4800 | 1320 | 19144 | 130 | 0.49 |
| 12 | 1/2" | 12.3 | 13.5 | 19.0 | 20.6 | 0.8 | 1.5 | 23.0 | 275 | 4000 | 1100 | 15956 | 180 | 0.59 |
| 16 | 5/8" | 15.5 | 16.7 | 22.2 | 23.8 | 0.8 | 1.5 | 26.2 | 250 | 3630 | 1000 | 14500 | 200 | 0.71 |
| 19 | 3/4" | 18.6 | 19.8 | 26.2 | 27.8 | 0.8 | 1.5 | 30.1 | 215 | 3120 | 850 | 12472 | 240 | 0.89 |
| 25 | 1" | 25.0 | 26.4 | 34.1 | 35.7 | 1.0 | 2.0 | 38.9 | 165 | 2400 | 650 | 9572 | 300 | 1.37 |
| 32 | 1.1/4" | 31.4 | 33.0 | 43.3 | 45.7 | 1.0 | 2.0 | 49.5 | 125 | 1820 | 500 | 7252 | 420 | 2.27 |
| 38 | 1.1/2" | 37.7 | 39.3 | 49.6 | 52.0 | 1.3 | 2.5 | 55.9 | 90 | 1310 | 360 | 5220 | 500 | 2.44 |
| 51 | 2" | 50.4 | 52.0 | 62.3 | 64.7 | 1.3 | 2.5 | 68.6 | 80 | 1160 | 320 | 4640 | 630 | 3.00 |
| 64 | 2 1/2" | 63.0 | 65.2 | 74.6 | 77.8 | 1.3 | 2.5 | 83.0 | 70 | 1015 | 280 | 4060 | 760 | 3.47 |
