| Prod Model: |
stainless steel woven wire mesh |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Width: 2',2.5',3',4',5'length:15m And 30: |
Mesh Size:1mesh-635mesh |
| Material: |
SUS304 |
| Hole Shape: |
Square |
| Application: |
Cages |
| Type: |
Stainless Steel Plain Wire Mesh |
| Material Type: |
Stainless Steel Wire |
| Weave Technique: |
Plain Weave |
| Wire Mesh Width: |
1m |
| Technique: |
Woven |
| Nickels: |
8% |
| Certification: |
ISO9001 |
Product Description
Typical Weaving Patterns for Stainless Steel Wire Mesh:
Plain weave, twill weave, Dutch weave. Plain Dutch weave, twill Dutch weave
Material: Stainless steel wire in202, 302, 304, 304L, 316, 316L and so on. The stainless steel mesh 202, 302, 304, 304L, 316, 316L, thet used for filtering and sieving and so on.
Specs: Square wire mesh ranges from 1 mesh to 635mesh; Dutch wire mesh ranges from 8 mesh X 85mesh to 400 mesh X 2800 mesh. We can also custom make stainless steel wire mesh for you.
General specification:
The standard width: 0.6m-1.5m
The standard length: 30m/roll
The suitable wire diameter: 0.25mm-2.0mm
Mesh/inch: 3-400 mesh
Aperture: 6.27mm-0.0385mm
Function: Acid-resistant, alkali-resistant, hot-resistant, pulling force & wear-resisting strong.
Application: As slurry mesh in oil petroleum; As filter screen in chemical & chemical fiber industry; As acid-washing mesh in electric plating, screening and sieving of solid materials, liquid filtration and solid-liquid separation, etc. In petroleum, chemical engineering, foodstuff, pharmaceutical and machine building industries.
| Specification List of Stainless Steel Wire Mesh |
| Mesh/Inch | Wire Gauge(SWG) | Aperture in mm |
| 3mesh x 3mesh | 14 | 6.27 |
| 4mesh x 4mesh | 16 | 4.27 |
| 5mesh x 5mesh | 18 | 3.86 |
| 6mesh x 6mesh | 18 | 3.04 |
| 8mesh x 8mesh | 20 | 2.26 |
| 10mesh x 10mesh | 20 | 1.63 |
| 20mesh x 20mesh | 30 | 0.95 |
| 30mesh x 30mesh | 34 | 0.61 |
| 40mesh x 40mesh | 36 | 0.44 |
| 50mesh x 50mesh | 38 | 0.36 |
| 60mesh x 60mesh | 40 | 0.30 |
| 80mesh x 80mesh | 42 | 0.21 |
| 100mesh x 100mesh | 44 | 0.172 |
| 120mesh x 120mesh | 44 | 0.13 |
| 150mesh x 150mesh | 46 | 0.108 |
| 160mesh x 160mesh | 46 | 0.097 |
| 180mesh x 180mesh | 47 | 0.09 |
| 200mesh x 200mesh | 47 | 0.077 |
| 250mesh x 250mesh | 48 | 0.061 |
| 280mesh x 280mesh | 49 | 0.060 |
| 300mesh x 300mesh | 49 | 0.054 |
| 350mesh x 350mesh | 49 | 0.042 |
| 400mesh x 400mesh | 50 | 0.0385 |
| Mesh Count ( Warp x Weft) | Wire Dia mm (Warp x Weft) | Micron Rating |
| 8 x 85 | 0.360 x 0.320 | 320-340 |
| 12 x 64 | 0.580 x 0.420 | 265-285 |
| 14 x 88 | 0.500 x 0.350 | 215-235 |
| 24 x 100 | 0.350 x 0.250 | 115-125 |
| 30 x 150 | 0.230 x 0.180 | 95-100 |
| 40 x 200 | 0.180 x 0.140 | 70-75 |
| 50 x 250 | 0.140 x 0.114 | 55-60 |
| 80 x 400 | 0.125 x 0.071 | 40-45 |
| Mesh | Wire Dia. (MM) | Microns | Material(AISI) |
| 80meshX700mesh | 0.102/0.070 | 0.043 | 304 or 316 |
| 165meshX800mesh | 0.071/0.041 | 0.037 | 304 or 316 |
| 150meshX800mesh | 0.069/0.053 | 0.035 | 304 or 316 |
| 200meshX600mesh | 0.053/0.046 | 0.030 | 304 or 316 |
| 150meshX1000mesh | 0.069/0.053 | 0.025 | 304 or 316 |
| 165meshX1400mesh | 0.066/0.041 | 0.021 | 304 or 316 |
| 200meshX1400mesh | 0.053/0.046 | 0.016 | 304 or 316 |
| 325meshX2300mesh | 0.036/0.025 | 0.008 | 316 or 316L |
Anping Xingmao Metal Wire Mesh Co., Ltd. is located at Anping County, Hebei Province, the famous Wire Mesh Town in China. XingMao is a one of the 5 biggest wiremesh companys in China, has advanced technology and equipment of production, test and inspection. The products are all inspected by our professional inspection team. We can design and develop different wire mesh products upon customers requirements or drawings.
Our main products include:
Gabion basket,
Gabion box,
Security Fence,
Garrison Fencing,
Perforated metal sheet,
Stainless steel wire mesh,
Galvanized iron wire,
Black annealed wire,
Alumium alloy wire mesh,
Brass wire mesh,
Copper mesh etc,
Which are widely applied in petroleum, chemical, food, construction and other industries.
Our export amount is up to 65, 000.00 dollars averagely per month. We mainly export to Europe, America, South Amercia, East and south Asia, MID east district, and some parts Africa countrys. With a dozen of years, we have entered into steady business with hundreds of customers at home and abroad.
General Manager, on behalf of all employees of Xing Mao, warmly welcomes you contact us for further information! We trust we can cooperate well based on mutual benefit and trust!
