Material: |
Galvanized Iron Wire |
Application: |
Gabion Mesh |
Hole Shape: |
Square |
Usage: |
Road Building |
Technics: |
Welded |
Surface Treatment: |
Galvanized |
Size: |
2m x 1m x 1m |
Aperture: |
60*80mm |
Product Description
Welded wire gabion mesh and Hexagonal gabion mesh
Gabion mesh have suqare hole and hexagonal hole
using welding and weaving
and
According to the using situation to purchase
High quality welded gabion boxes
Welded gabion box is widely used in retaining wall structures, rockfall and soil protection and so on. Welded gabions are filled on site with hard and durable stone to form mass gravity structures. And welded gabions are quicker and simpler to install than woven mesh gabions.
Welded gabion box is manufactured from cold steel wire for tensile strength. It is electrically welded together then hot dipped galvanized or PVC coated, ensuring a longer life. There are galvanized welded gabion and welded PVC gabions. Gabion boxes are designed on the principle of mass earth retaining wall. The strength of the wire mesh helps to with- stand the forces generated by the retained soil.
Note: Standard wire diameter (mm)
Heavily Galvanised or zinc coated wire 2.20, 2.50, 2.70, 3.00, 4.00, 5.00.
Polymer coated on Heavily Galvanised or zinc coated wire 2.5/2.8, 2.7/3.0, 3.0/3.3, 4.0/4.3, 5.0/5.3.
Welded gabion box advantages:
Blends easily and harmoniously with the natural surroundings.
Low cost alternative to concrete or masonry structures.
Very high resistance to natural forces due to better tensile strength.
Can withstand any unpredictable movement or settlement without loss of stability.
Simple and speedy installation, making it cost effective.
Quality finish and appearance is more aesthetically pleasing.
More rigid than woven mesh resulting in a more uniform finish when built.
Quicker and cheaper to install than Woven Mesh gabions because no pre-stretching required.
Special gabions sizes and mesh such as gabions with 4mm front mesh and 3mm mesh else can be available.
Applications of the welded gabion box:
Our welded gabion box is widely used for the following application: Control and guide of water; Preventing of rock breaking; Water and soil, roadway and bridge protection; Strengthening structure of soil; Protection engineering of seaside area and retaining wall structures; Hydraulic structures, dams and culverts; Coastal embankment works; Architectural feature retaining walls.
Nominal Box sizes m) | No. of diaphragms (no.) | Capacity per box(m3) |
1.0x1.0x0.5 | Nil | 0.50 |
1.0x1.0x1.0 | Nil | 1.00 |
1.5x1.0x0.5 | Nil | 0.75 |
1.5x1.0x1.0 | Nil | 1.50 |
2.0x1.0x0.5 | 1 | 1.00 |
2.0x1.0x1.0 | 1 | 2.00 |
3.0x1.0x0.5 | 2 | 1.50 |
3.0x1.0x1.0 | 2 | 3.00 |
4.0x1.0x0.5 | 3 | 2.00 |
4.0x1.0x1.0 | 3 | 4.00 |
More communication, perfect cooperation
Commonly used specifications:
Mesh Size | No. Of Diaphragm | Approximate Dimensions and volumes | Tolerance | Color code | Wire |
Length | Width | Depth | Capacity |
60*80 80*100 80*120 90*110 100*120 110*130 120*150 | 1 | 2.0m | 1.0m | 0.5m | 1.0m | 5% | Silver Bright , Dark Green, Gray,Black | Heavily galvanized, PVC Coated galfan coated wire Diameter: 2.0, 2.2, 2.4, 2.7, 3.0mm |
1 | 2.0m | 1.0m | 1.0m | 2.0m |
2 | 3.0m | 1.0m | 0.5m | 1.5m |
2 | 3.0m | 1.0m | 1.0m | 3.0m |
3 | 4.0m | 1.0m | 0.5m | 2.0m |
3 | 4.0m | 1.0m | 1.0m | 4.0m |
1 | 2.0m | 0.5m | 0.5m | 0.5m |
2 | 3.0m | 0.5m | 0.5m | 0.75m |
4 | 5.0m | 1.0m | 0.5m | 2.5m |
4 | 5.0m | 1.0m | 1.0m | 5.0m |
5 | 6.0m | 1.0m | 1.0m | 6.0m |
