| Prod Model: |
Hammer Tips |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Hammer Tips |
| Hardness: |
63HRC/700bhn |
| Tensile Strength: |
630MPa Min |
| Shearing Strength: |
250MPa Min |
| Micro-Structure: |
Carbide+Martensite+Retained Austenite |
| Application: |
Industrial Equipment Wear Protection |
| Materials: |
White Iron |
| Types: |
Standard, Flared, Butterfly |
Product Description
Sugar Mill White Iron Shredder Hammer Tips
1) shredder hammer tips (15/3CrMo white iron with mild steel backing,700BHN-63HRC) have fine shredding and crushing performance.
2) Hammer Tips are available in many different shapes and styles. They have sharp edges at the start of use that retain their sharpness and cutting efficiency longer than conventional hard facing.
3) Application
Hammer tips can be used in sugar or coal industry to do crushing and shredding performance, it has excellent impact and abrasion resistance properties & enhanced service life.
4)These shredder hammer tips are used as an alternative to conventional hardfacing in:
--Crusher mills
--Hammer mills
5)These hammers find application in
I) Sugar Industry
II) Mining & Mineral Processing Industry.
III) Cement & Steel Industry
We can produce according to your drawings and specifications.(standard Hammer Tips / Flared Hammer Tips, Butterfly Hammer Tips)
6) TYPE 1 HAMMER TIPS: (FLAT TYPE)
Item No. | Size(mm) | N.W.(kg) |
| HC1 90-90 | 90x90x45 | 2.9 |
| HC1 90-50 | 90x50x45 | 1.6 |
| HC1 50-50 | 50x50x38 | 0.7 |
| HC1 80-80 | 80x80x45 | 2.4 |
| HC1 100-100 | 100x100x45 | 3.6 |
| HC1 64-64 | 64x64x40 | 1.2 |
| HC1 80-56 | 80x56x45 | 1.6 |
TYPE 2 HAMMER TIPS: (V TYPE)
| Item No. | Size(mm) | N.W(kg) |
| HC2 90-90 | 90x90x50 | 3.0 |
| HC2 80-56 | 80x56x50 | 1.8 |
TYPE 3 HAMMER TIPS: (U TYPE)
Item No. | Size(mm) | N.W.(kg) |
| HC3 90-90 | 90x90x50 | 3.0 |
| HC3 90-50 | 90x50x55 | 1.8 |
| HC3 90-56 | 90x56x55 | 1.9 |
Our Typical products and service: wear liner/plate, Hammer tips, Chute liners, overlay wear plate, CrC wear parts, bucket wear attachments, bi-metallic castings, hi-chrome castings and wear solutions
Hunan Hyster Material Technology Co., Ltd., formerly name is hyper casting parts Co., Ltd., is an independent international supply, design and engineering company, in operation since 1995, we specializes in high quality of wear products.
Hyster offer our clients a wide range of wear products and professional wear solutions. We also welcome custom made one off's and consumables.
Some of our products and services:
--Wear plates, wear liners
--Chocky bars and wear buttons
--Wear blocks, wear bars
--Custom made wear liners
--Bucket repair and protection
--Full Fabrication services
--Sugar mill hammer tips
--Drilling, milling or machining
--Casting/Investment casting
--Fast service and timely delivery
With strict management system and strong technical base, Hyster Corporation is committed to provide high-quality products and services for the fields of Mine and Mining, Quarrying, Electrical power, Cement, Sugar, Aviation, Marine, Railway, Engineering plant and Petroleum machinery industries.
Quality is very important to the development of Hyster Corporation. The company strictly operates according to ISO9001: 2000 quality management system. Over 95% products have been sold to Australia, Canada, South Africa, Brazil, America, Chile, Indonesia, Argentina, Thailand, Mexico, Russia, Holland, as well as many other countries and areas.
Moreover, breaking out of the traditional practice that only provide OEM products, our company has created the new sales concept whose main points are providing solutions, terminal products and customer services, which enables us to better fulfill customer specifications in a positive manner.
Please contact us directly with any questions or inquiries!
