| Prod Model: |
30/40-600/700 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Synthetic Diamonds for Grinding |
| Type: |
Yellow |
| Shape: |
Cubic |
| Process Type: |
Press Machine |
| Grit: |
30/40 - 500/600 |
| Material: |
Diamond |
| Usage: |
Polishing |
Product Description
Diamond powder grit :
0.25um - 2000um
Usage : for making all kinds of diamond tools , like : diamond drill bit , diamond grinding wheel , diamond saw blade , and so on .
0.25um - 50um for polishing hard metal , making polishing tools
50um - 2000um for diamond drill bit , diamond saw blade , and so on .
Color : grey , yellow , green , white , gold
If you need diamond powder , please tell me your grit and application , then i will send you picture and price for your reference .
Please contact with Ms. Belinda Mobile phone : 0086-15515768457
Thanks for your supporting . ^_^
Synthetic Diamond
1.High purity
2.Wear-resisting
3.Girt uniform
4.Stable quality
5.Enough ability to supply
RVD Diamond :
Feature: Most crystals are irregular with rough surface.
Usage: For making resin bond and vitrified bond abrasive tools, electroplated products and drilling tools etc.
Size:30/40,40/45,45/50,50/60,60/70,70/80,80/100,100/120,120/140,140/170,170/200,200/230,230/270,270/325,325/400,400/500.
MBD Diamond
Feature: Well facetted crystals with smooth surface and high compressive strength.
Usage:For making metal bond abrasive tools etc.
Size:30/35,35/40,40/45,45/50,50/60,60/70,70/80,80/100,100/120,120/140,140/170,170/200.
SMD Diamond
Feature: Well facetted and very clear crystals with smooth surface and high compressive strength.
Usage:For making saw blades drilling and dressing tools etc.
Size:20/25,25/30,30/35,35/40,40/45,45/50,50/60,60/70,70/80,80/100,100/120,120/140,140/170.
Dianmond micro powder
Feature: Grit is uniform.Don't contain impurities.High purity.
Usage:For making polishing pads,polishing disc,diamond compound,PCD,diamond wire dies,polishing ceramics,electronic devices etc.
Size:0.25um,0.5um,1um,1.5um,,,,,50um.
Ni & Ti coating synthetic diamond powder
Size:
Micron powder: 0.5um to 50um.
Diamond mesh powder: 30/40,40/50,,,to 400/500
Usage: for making diamond drawing wire, diamond drill bit etc.
Feature: 30% & 56%
Standard of International | Standard of China | Mesh |
| 0-0.5 | W0.5 | 30000 |
| 0-1 | W1 | 25000 |
| 0.5-1 | W1 | 20000 |
| 0.5-1.5 | W1.5 | 15000 |
| 0-2 | W2.5 | 8000 |
| 1-2 | W2.5 | 8000 |
| 1.5-3 | W3.5 | 5000 |
| 2-4 | W3.5+ | 4000 |
| 2.5-5 | W5 | 3000 |
| 3-6 | W5+ | 2500 |
| 4-8 | W7+ | 2000 |
| 5-10 | W10 | 1500 |
| 6-12 | W10+ | 1200 |
| 8-12 | W10+ | 1000 |
| 68-16 | W14+ | 900 |
| 10-20 | W20 | 800 |
| 12-22 | W20+ | 700 |
| 20-30 | W28+ | 600 |
| 22-36 | W40 | 500 |
| 36-54 | W50 | 400 |
Zhecheng Hongxiang Superhard Material Co., Ltd. Affiliated with Wanke Group, is a highly professional and experienced manufacturer of synthetic diamond powder & diamond tools in China. We have specialized in this field over 27 Years and always dedicated to the produce the diamond tools in high quality and good service.
Our products include,
Synthetic diamond
Diamond powder
Diamond saw blade
Diamond drill bit
Poly crystalline Diamond composite ( PDC )
PCD wire drawing dies
Diamond glass tools
Diamond polishing pad
Diamond cutting tools
Diamond grinding tools
Diamond wheels
Diamond tools, etc.
Why choose us?
1. Since 1990, with over 27 years diamond tools manufacturer experience.
2. Rich experience in OEM order
3. Advanced production equipment
4. Own design team, can help you custom the packaging
5. Own provincial engineering technology center
6. D&B and ISO9001 Certificates
We are a professional synthetic diamond powder & diamond tools company integrating development, production and sales. Factory located in middle of China-Henan, with more than 124000 square meters. "High quality products, competitive prices, and classic services" is the soul of our business.
Warmly welcome all partners to join us for mutual benefits cooperation.
