| Prod Model: |
WRC32 |
| Product Name: |
Diamond Cutting Wheel Machine |
| Power: |
11kw |
| Max.Wheel: |
32 Inch |
| Warranty: |
One Year |
| Function: |
Repair Wheel |
| Voltage: |
380V/220V |
| Control System: |
Syntec |
| Accessory: |
Diamond Cutter Tools |
| Max. Swing Diameter: |
800mm |
| Turret Type: |
4 Station Electrix Turret |
| Process Usage: |
Metal-Forming CNC Machine Tools |
| Control Method: |
Open-Loop Control |
| Numerical Control: |
CNC/MNC |
| Performance Classification: |
High-End CNC Machine Tools |
| Movement Method: |
CNC |
Product Description
WRC32 Alloy wheel repair cnc lathe for diamond cutting wheel machine
Specifciation:| ITEMS | WRC32 |
| Max. swig over bed (mm)(inch) | Φ820 (32') |
| Max. Size of alloy wheel (inch) | 32 inch |
| Adjustable stroke of carrier in X direction | 100mm |
| Cross slide travel (mm) | 450 |
| Width of the rail (mm) | 400 |
| Length of the rail (mm) | 1650 |
| Size of the three-jaw chuck (inch) | 16' |
| Range of spindle speed (RPM) | 50~1800 |
| Spindle speed control | Automatic |
| Spindle bore (mm) | Φ82 |
| Taper of spindle bore | 1:20(Φ90) |
| Max. size of tool post | 25×25mm |
| Stations of tool carrier | 4 position |
| Min. setting unit of motor | (Z) long 0.001mm,
(X) cross 0.001mm |
| Moving speed of post | (Z) long 8m/min,
(X) cross 6m/min |
| Motor power | 11KW |
| Machine size | (L×W×H) (mm³) | 2970 ×1660×2080 |
| Package size | | 3120×1810×2350 |
| Net weight | 3500kgs |
Standard configuration:1-3-Jaws Chuck(With Special Soft Jaws)
2-Manual Quick Change Toolpost ,four-station turret,
3-Automatic lubrication system,
4-Turning the cooling system.
5-With probing system(TP300 Pioneer Sensing Probe TP300;)
6-Diamond Cutter 1 set
7-cnc controller syntec
8-Full Enclose(Security Guard Door)
9-Specific Digital Optimization Software
10-Training Video CD
11-Work Lighting System
Services:1-After-sales services: Warranty is one year; we would offer the parts (quality problem) free of charge during this period, freight collect.
2-Alloy Wheel Refurbishemnt Advice from REAL WORLD experts in the Diamond Cutting and Alloy Wheel Refurbishment industry
3-Mechanical Support
4-Software Support
5-Comprehensive Training
6-Probe alloy wheel profile
