| Prod Model: |
HXSAW |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diameter: |
105mm, 115mm, 125mm, 175mm |
| Hole Size: |
20/22.23mm |
Product Description
X turb diamond saw blade super thin hot pressed for granite and ceramic tiles
Product video:
https://youtu.be/8AnBeWrcchQ
Specifications
Diamond tools:
1.30% faster Sharpness
2.30%-40% higher Cutting Life
3.Noise reduction by 30%
4.Save 20% Power Absorption
HOT PRESSED SUPER THIN TURBO BLADES
| Diameter | Hole Size | Thickness | Segment Height |
| 105mm | 20/22.23mm | 1.2mm | 10mm |
| 115mm | 22.23mm | 1.2mm | 10mm |
| 125mm | 22.23mm | 1.2mm | 10mm |
| 175mm | 22.23 | 1.4mm | 10mm |
Other specifications are available upon request. Please specify wet or dry use.
Features:
Super thin turbo rim and soft band are especially designed for fast and smooth cutting.
Applications:
All kinds of ceramic tiles and porcelain.
Machinery:
Angle hand grinder, circular saw.
Other diamond tools:
4" Diamond Cup Wheel for Hard Concrete Stone Masonry Grinding
Application
The most efficient tools for fast grinding, edge-trimming, smooth shaping and finishing of concrete, stone, or masonry material, etc
Advantage
Diamond grinding wheel for concrete
Turbo segment, metal body
Good balanced
Fast rough dry/water-cooling
Size
Diameter: 100mm, 80mm
Grti size: 40#, 80#, 100#, 120# etc
Other size can be customized
Sample is provided
Usage
Used for marble, granite, terrazzo, refractory brick, concrete, specific stone grinding
| specification | diameter | hore | Tooth thickness | height |
| 80mm | 20/22.23/16mm | 2mm | 12mm |
| 100mm | 20/22.23/16mm | 3mm | 12mm |
| type | Normal turbo type, single row |
| application | Mainly for stone, concrete abrasive and grinding, High efficiency, long life. |
| service | 1. If any special requirement about diamond grits, please notify us.
2. very discount is given to big order.
3. OEM etc. |
Zhecheng Hongxiang Superhard Material Co., Ltd. Affiliated with Wanke Group, is a highly professional and experienced manufacturer of synthetic diamond powder & diamond tools in China. We have specialized in this field over 27 Years and always dedicated to the produce the diamond tools in high quality and good service.
Our products include,
Synthetic diamond
Diamond powder
Diamond saw blade
Diamond drill bit
Poly crystalline Diamond composite ( PDC )
PCD wire drawing dies
Diamond glass tools
Diamond polishing pad
Diamond cutting tools
Diamond grinding tools
Diamond wheels
Diamond tools, etc.
Why choose us?
1. Since 1990, with over 27 years diamond tools manufacturer experience.
2. Rich experience in OEM order
3. Advanced production equipment
4. Own design team, can help you custom the packaging
5. Own provincial engineering technology center
6. D&B and ISO9001 Certificates
We are a professional synthetic diamond powder & diamond tools company integrating development, production and sales. Factory located in middle of China-Henan, with more than 124000 square meters. "High quality products, competitive prices, and classic services" is the soul of our business.
Warmly welcome all partners to join us for mutual benefits cooperation.
